VMAX XTR16-400 Group L16 6 Volt 400AH Deep Cycle, AGM Aerial Lift Battery

QTY: 1 VMAX XTR16-400 Superior Plates have an expected life span of 10 to 12 years in float service applications. Nominal Voltage:6V, 20Hr Capacity: 400AH, CA: 1100A, RC 25A (min): 940, RC 75A (min): 265, Energy (kWH): 2.66, Terminal Posts: SAE+5/16"(Coarse-18) STUD, Dimensions: 11.6"w x 7.1"d x 15.9"h/16.7"th*, Weight: 125lb, Charging Current*: 25A - 120A, Charging Voltage: 7.2V - 7.35V, Float Voltage: 6.8V - 6.9V 25A @ 1.75/Cell 950Min 75A @ 1.75/Cell 270Min Recommended Charging Options: • AC Chargers: Any Quality Brand AGM- Smart & Microprocessor controlled- charger with the recommended specs above can be used. • Solar Panel: 300W-800W (200W may be used if the Depth of Discharge would not exceed 50%). * Warning: Do not use a charger with a smaller amperage than the recommended Charging Current shown above. Maintainers should ONLY be used to maintain a fully charged battery but NEVER as a charger. **Total Height including terminal post. Operating Temperature Range: • Discharge: -4~140F • Charge: 14~140F • Storage: -4~140F Temperature Compensation: • Cycle use: -15mV/C • Standby use: -10mV/C BCI Group Codes*: Matching Termination: L16
