Tigertronics SignaLink USB SLUSB13I

(No ratings yet)

Key item features

The SignaLink USB supports virtually all sound card digital and voice modes including FT8, PSK31, JT65, WINMOR, Winlink Express, VARA FM 1200, RTTY, SSTV, CW and EchoLink, to name a few.
The Signalink USB p/n SLUSB13I is compatible with virtually all Icom radios that have a 13-pin DIN Accessory Port. This includes but is not limited to the radios listed below.
If your radio is not listed below then be sure to check our other listings or contact us. We have a number of different SignaLink part numbers available to fit most standard radios.
SLUSB13I Compatible Icom Radios -- IC-78, IC-703**, IC-706, IC-706MKII, IC-706MKIIG**, IC-718, IC-7000**, IC-7100**, IC-7200, IC-7300, IC-7410, IC-9100**
NOTE: The SignaLink USB p/n SLUSB13I CANNOT be used with the IC-275 and IC-970 due to the radio's non-standard Accy Port jack. If you want to use the SignaLink with these two radios then you will need to connect it to the mic jack. If you wish to do this then please see our listing for the SignaLink USB p/n SLUSB8R.
FCC Certified - Unlike virtually all of our competitors, the SignaLink USB has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Built-in Low Noise Sound Card - This provides optimum performance and frees your computer's existing sound card for other uses. It also greatly simplifies installation and operation, by reducing the number of cable connections, and by providing consistent performance that is independent of the computer's sound card.
Simple Installation - The SignaLink USB has only one USB connection to the computer, and in most cases, only one connection to the radio*. There are no computer audio cables to get mixed-up!
Works with virtually ALL Radio Mic, Data, and Accessory Ports - The SignaLink USB works with virtually ALL radios, and can be attached to your radios Mic, Data, or Accessory port. This allows most users to attach the SignaLink to the back of the radio (Data or Accessory Port) and leave the microphone plugged in!

Specs

Connector type
USB
Cable length
3'
Brand
SignaLink
Compatible brands
Icom America
Compatible models
IC-78, IC-703, IC-706, IC-706MKII, IC-706MKIIG, IC-718, IC-7000, IC-7100, IC-7200, IC-7300, IC-7410, IC-9100
Model name
SignaLink USB

Current price is $139.95

Price when purchased online

Out of stock

How do you want your item?

Out of stock

About this item

Product details

The SignaLink USB comes with all of the cabling needed to use it with your computer and radio (see below for a list of compatible radio models), as well as sample software to get you started. This listing includes the following items: SignaLink USB Detachable Radio cable (3ft length), Detachable USB Cable (6ft length), Jumper Wires (set of 6, cut and stripped, and ready to use - NO soldering required!), Printed Manual, Free Software CD (Windows), Allen Wrench, Rubber Feet

The SignaLink USB supports virtually all sound card digital and voice modes including FT8, PSK31, JT65, WINMOR, Winlink Express, VARA FM 1200, RTTY, SSTV, CW and EchoLink, to name a few.
The Signalink USB p/n SLUSB13I is compatible with virtually all Icom radios that have a 13-pin DIN Accessory Port. This includes but is not limited to the radios listed below.
If your radio is not listed below then be sure to check our other listings or contact us. We have a number of different SignaLink part numbers available to fit most standard radios.
SLUSB13I Compatible Icom Radios -- IC-78, IC-703**, IC-706, IC-706MKII, IC-706MKIIG**, IC-718, IC-7000**, IC-7100**, IC-7200, IC-7300, IC-7410, IC-9100**
NOTE: The SignaLink USB p/n SLUSB13I CANNOT be used with the IC-275 and IC-970 due to the radio's non-standard Accy Port jack. If you want to use the SignaLink with these two radios then you will need to connect it to the mic jack. If you wish to do this then please see our listing for the SignaLink USB p/n SLUSB8R.
FCC Certified - Unlike virtually all of our competitors, the SignaLink USB has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Built-in Low Noise Sound Card - This provides optimum performance and frees your computer's existing sound card for other uses. It also greatly simplifies installation and operation, by reducing the number of cable connections, and by providing consistent performance that is independent of the computer's sound card.
Simple Installation - The SignaLink USB has only one USB connection to the computer, and in most cases, only one connection to the radio*. There are no computer audio cables to get mixed-up!
Works with virtually ALL Radio Mic, Data, and Accessory Ports - The SignaLink USB works with virtually ALL radios, and can be attached to your radios Mic, Data, or Accessory port. This allows most users to attach the SignaLink to the back of the radio (Data or Accessory Port) and leave the microphone plugged in!
