Telewave ANT150F2 148-174 MHz Fiberglass Omnidirectional Antenna

New

TELEWAVE

ANT150F2

148-174 MHz 2.5dBd Fiberglass Omni-directional Base Antenna

TELEWAVE's ANT150F2 omnidirectional antenna operates in the frequency range 148 – 174 MHz.
The 2.15 dBi gain VHF fiberglass collinear omni antenna can handle 500 W.
It features a recessed N Female connector.
A dual clamp set for mounting to a 1.5 in – 3 in diameter support pipe is included.
The rugged, high tech radome and brass and copper element construction with a path to DC ground potential for lightning protection ensure survivability in all environmental conditions.
The Telewave ANT150F2 omnidirectional antenna is ideal for use in all environmental conditions.

Omni Antenna
Frequency Range (MHz)	148-174
Omni Antenna Spec1
Gain	2.5 dBd
Bandwidth (MHz)	26
Electrical Downtilt	0
Power (watts)	500
Vert. Beamwidth	38 Deg
Termination	Recessed N-Female (7-16 DIN opt.)
Jumper Supplied	24" RG213 N-Male to N-Male
Mounting Hardware	Clamp Set for 1.5" - 3.0" Dia. Mast
Support Pipe Dia. (in.)	2.75
Overall Length (in.)	60
Omni Antenna Spec2
Wind Rating (mph)	200
Net Weight (lbs.)	16.0 LBS
Shipping Method	UPS
Warranty	5 Year
Ship Weight (lbs.)	16
Weight	17.06 lbs

Item Weight	16 lb
Item Height	60 in
Item Width	2.75 in
Item Length	2.75 in
Gain dBd	2.5 dBd
Gain dBi	4.65 dBi
Jumper Included	Yes
RF Connectors	N Female
Polarization	Vertical
Specific Frequency	148-174 MHz

Vertical Beamwidth	80 deg
Maximum VSWR	1.5:1
Maximum Rated Wind Velocity	200 mile/h
Tuned Frequency (MHz)	N/A
Lightning Protection	DC Ground
Lateral Thrust @ RWV (lb)	50 @ 100 MPH
Support Pipe Dia.	2.75"
Support Pipe Length	11.5"
Frequency Band	VHF
