Sniper 19-185 Sniper EFI Fuel Tank System 255 LPH

Compatible with 1967-1972 Chevrolet®/GMC Truck with Under Bed Mounted Tank. This product is not created or sold by GM®.;

The 19-185 fuel system kit is designed for the 1967-1972 Chevy/GMC trucks. This fuel tank mounts under the truck bed using the flanges to bolt in place. The tank is designed to bolt up to the bottom side of the frame rails but it can be mounted in different configurations including on top or even in-between the rails in some cases. It is up to the installer to drill and locate the mounting holes. Mounting hardware is not included. The fuel filler neck will go up through the bed floor. You can purchase the optional 19-186 Side Fill Kit to mount fuel filler on the bedside.

The kit includes the 18-gallon tank, a 255 lph fuel pump to support up to 550 hp @ 60 PSI at 13.5 volts with a 10.4 AMP draw, internal baffling, and a fuel level sender. The tank is powder coated silver for corrosion resistance and great looks.

Tank size is 32-1/4" x 20-1/2" x 9-3/4" including the mounting flange and 28" x 20-1/2" x 9-3/4" measured without the mounting flange.;
