Edelbrock 77589 Victor Jr. Series Cylinder Head

Cylinder HeadVictor Jr. Series Cylinder HeadVictor Jr. Series Cylinder Head; 23 Degree; Complete; Chamber Size 64cc; 450-550hp; Sdt. Intake Flange; +0.125 Exh. Port; Angled Plug; Single; Chevy Small Block Race Engines;SPECIFICATIONS:

Cylinder Head Type: Standard

Emission: Non-Emissions

Engine Make/Size: Chevy Small Block (262-400)

Finish: Cast Aluminum

Preparation: Bolt On (Not Required)

Type: Complete

Usage: Competition

WARNING CA Proposition 65: Yes

WARNING CA Proposition 65 Message: WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov.

FEATURES:

Out-of-the-Box Bolt-On Performance

Affordable; Top Quality

Race-Winning Set-Up

Accepts Standard 23 Deg. Valvetrain Hardware

64cc Chamber Ideal for Entry Race/Hi-End Street

Affordable maximum power cylinder head for competition and ultra high-performance street. 530-580 hp potential, out-of-the-box, for a cost effective, race-winning set-up. 64cc chambers yield about 12.5:1 compression with a 12cc domed piston in a 350 V8. These cylinder heads feature angled spark plug holes and accept standard 23� valvetrain hardware. INSTALLATION NOTE: Check cam manufacturer's specs for compatibility with valve springs for spring rates. Match with Edelbrock head gasket sets. Use Head Bolt Kits for easy installation. These heads require the use of a 14mm x 3/4" reach, flat gasket spark plug with a heat range appropriate to your application. Deck thickness: 9/16", rocker stud diameter: 3/8", pushrod diameter: 7/16" (width of slot in guide plate).When you design and sell the best-engineered performance products in the world, you have to have a rigorous testing program. Why? Without adequate testing, there's no way to stand behind your product with confidence. That's why every product we design and sell at Edelbrock is tested and approved by Edelbrock engineers in a real world environment on state-of-the-art equipment. Our three Super Flow computerized engine dynos are capable of measuring 11 separate engine variables up to speeds of 12,000 rpm. For 2007, we added a new Super Flow SF902 engine dyno. It's fully automated and programmable to simulate various driving situations, and is equipped with WinDyn software for the very latest in testing equipment. For real-world tuning, there's our Super Flow model SF-840 eddy-current chassis dyno that can handle up to 1,000 hp at the wheels and speeds of 200 mph. When all testing is completed, the results evaluated, and the part has passed all performance criteria, then, and only then, is the product deemed ready for production. These precise testing procedures are applied to the entire Edelbrock line for performance that's guaranteed. Edelbrock test vehicles are driven by Edelbrock engineers and employees to get a "real world" feeling for the performance improvements. Our products are also tested and used by professional race car teams and drivers. Working with these talented individuals is just another extension of our research and development process so when we say "proven performance" we really mean it! Top racing teams in all forms of motorsports rely on Edelbrock to produce parts that they can count on to win races and championships. Further underscoring our commitment to the racing community, Edelbrock is the only aftermarket intake manifold manufacturer licensed by NASCAR..
