Maxpeedingrods K04 KO4 Turbo for VW Bora Golf Sport Beetle Polo Audi A3 TT K04-001 1.8T 220HP

Turbocharger for VW Golf Sport Beetle for Audi For Seat 1.8L

Application:

K04 model:

for Audi A3 upgraded Engine FT 190 4EB/4EA/4EC 1999-2009

for Audi TT upgraded Engine FT 190 4EB/4EA/4EC 2001-2009

for Volkswagen BEETLE, Seat IBIZA upgraded Engine 4EB/4EA/4EC 1996-2009

Note:  The Car Make with K03 Model as below Need modify the intake pipe(our K04 compressor inlet is bigger than K03 model）:

1. For Audi A3 with AGU, ALN, ARZ engine 110 KW, 150 PS 1996-2003

2. For Audi A3 with AUQ, ARZ, APP  engine 132 KW, 180 PS 1996-2003

3. For Audi TT with AUQ  engine 132 KW, 180 PS 1998-2006

4. For Seat Leon with AJQ; APP; ARY; AUQ engine  132 KW, 180 PS 1998-2006

5. For Skoda Octavia  AUQ engine 132 KW, 180 PS 2001–2005

6. For Volkswagen Golf/Bora/Jetta with AUQ, ARZ Engine 2000-2009

7. For  Volkswagen New Beetle with 1.8L-5V langs,along Engine 2000-05

*IMPORTANT NOTICE:

1. This is an upgraded K04 turbo for K03-053 & K03 -052.Do not for K04-022.

2. K04 -001 turbo is different from K03-052 ＆ K03-053

(1)some modification are needed，compressor intake size is bigger than K03-052 or K03-053

       K03-052 ＆K03-053 compressor intake size is 45mm

       K04-001 compressor intake size is 48.7mm

(2)Silicone hose may need for K04-001 compressor intake connection.

3. Make sure your OE number is correct for K04-001,K03-052 and K03-053

Specification:

Turbo Model:  K04-001

Engine Model: 1.8L-5V

Engine Code:  AJQ, APP, AUM, AUQ, ARY

Cooling Type: Water & Oil Cooled

Bearing Type: Journal Bearing / Floating Bearing

Thrust Bearings: 270 Degrees

Hosepower: 162KW/220PS

Turbo Type: Individual

Package included

1x Turbocharger

2x Flange gaskets

2x Oil port gaskets

2x Water port gasket

1x Manual

1x Brochure

1x Sticker

Material:

1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃

2. Steel turbine wheel: K418 alloy -  high  oxidation stability and resistance  up  to 900℃

3. Compressor housing: ZL104 aluminum with lightweight

4. Compressor wheel/blades: Cast aluminium blades – superior air tightness & corrosion resistance

Performance：

1. OEM-quality and size with little modification

2. Rich experience in turbo production and own factory

3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:

1. 100% balancing Test by TURBOTECHNICS  VSR3

2. G3-min-Flow VNT Turbo testing

3.  Advanced Actuator Tester/Programmer
