Long Stroke Air Brake Chamber 3"/76mm Type 3030 Welded Clevis Replaces GC3030LCW

TORQUE HIGH-QUALITY LONG STROKE AIR BRAKE CHAMBER TYPE 3030 WELDED CLEVIS ? TR3030CLS-WC

- Combination with Welded Clevis - Long Stroke - Size 3030 - Square Bosses
- Superior Power Spring Technology
- Advanced powder coating process
- Resists corrosion and fatigue
- Double O-ring Centerseal
- Two o-rings for positive sealing and plastic bearings for long life
- World Class Diaphragm
- High quality rubber compound, resistant to heat and cold
- Rugged Service Housing
- 9 gauge steel, powder coated
- Self-piloting Dust Shield
- Sizes to fit all drum brake applications

REPLACES:
Haldex:GC3030LCW
Bendix:NT3030ELS-WC
Freightliner:HDX1373030215
Others:BTS-3030LS-WCR, GTA-3030LS-WCR

SPECIFICATIONS:
Actuator Type Size: 3030
Stroke Type: Long
Available Stroke: 3", 76mm
Length from mounting bracket to end of Spring Housing: 9-7/8", 251mm
Length of Piggyback: 7-3/8", 187mm
Dimension at rolled Spring Housing flange: 8-5/16", 211mm
Dimension at Service Clampband: 10-3/16", 259mm
Pushrod Length from face of Service Housing: 1"
Distance to Clevis Pin centerline from face of Service Housing: 2-1/4"
Weight: 21.9 lbs/9.9 kg
