IUSU Full Motion TV Wall Mount Bracket for Most 32-60 inch Flat/Curved TVs High-Strength Steel 28 32 40 43 48 50 55

Full Motion TV Wall Mount Bracket for Most 32-60 inch Flat/Curved TVs Holds up to 60lbs

This heavy-duty articulating TV wall mount fits TVs 32-60 inches and is designed with strength and versatility in mind.      The ultra-slim design allows the TV to fold flat against the wall 3 inches from the wall when pushed back, and then extend 15.4 inches from the center of the wall, so you can adjust it to save space for entertainment even when guests are at home.      Tilt ±10° and swivel ±60° to suit your different viewing positions, great for watching TV shows, video games, and fitness shows, whether you're sitting, standing, lying down, or sitting on the side, video chatting, etc.

Will the TV wall mount fit my TV?

First, please check your wall for wood studs, it can’t be used on concrete walls or drywall alone (Need to be installed with the anchor).

Next, the weight of your TV should be less than 60lbs/60kg.    Your TV should be at least 32 inches.

Then, mounting holes distance on the back of the TV must be less than 24" (600mm) horizontally and 16" (400mm) vertically.

Finally, please check the TV back area inside the 4 mounting holes to make sure there are not any cables outlets.    Otherwise, the plate may block the plugs.

Specifications:

Material: Alloy Steel

TV Size: 32-60" LED LCD OLED TVs

Max Load: 60lbs / 60kg

Tilt Angles: +5°/-15°

Swivel Angle: ±45°

Level Angle: ±3°

Extension Range: 3-14.84"

Support Brand: SONY/SAMSUNG/VIZIO/LG/Hisense/TCL/SHARP/Toshiba/Panasonic/Philips/SKYWORTH and more.

Mounting Hole Patterns: 200x100/200x200/300X200/300x300/400x200 400x300/400X400/500x300/600x200/600x400 (8"x4"/8"x8"/12"x8"/12"x12"/16"x8"/16"x12"/16"x16"/20"x12"/24"x8"/24"x16")
