Hallowell UW1288-2MEW Hallowell Metal-Wood Hybrid Locker, 12 in. W x 18 in. D x 78 in. H, 708 Midnight Ebony Body and Frame with Red Oak Doors, Double Tier, 1-Wide, Knock-Down

Fabricate lockers square, rigid and without warp, with metal faces flat and free from dents or distortion. Make all exposed metal edges safe to touch. Weld frame members together to form rigid, one-piece structure. Weld, bolt, or rivet other joints and connections as standard with manufacturer. Grind exposed welds flush. Do not expose bolts or rivet heads on fronts of locker doors or frames except for fastening of number plate.

• Type - Double Tier.
• Color - 708 Midnight Ebony Body and Frame with Red Oak Doors.
• 1-Wide.
• Knock-Down.
• Dimensions - 12 W x 18 D x 78 H in.

• All steel locker parts to be cleaned and coated after fabrication with a seven stage zinc/iron phosphate solution to inhibit corrosion, followed by a coat of high grade custom blend powder electrostatically sprayed and baked at 350 degrees Fahrenheit for a minimum of 20 minutes to provide a tough durable finish. Color to be selected from manufacturer's standard list of colors.

• Fabricate of 16 gauge (minimum) channels, with integral continuous door stop/strike formed on both latch and hinge side vertical members. Cross frame members of 16 gauge channel shapes, including intermediate cross frame members on double and triple tier (frames with doors over 18 in. high) lockers shall be securely welded to the vertical framing members to ensure rigidity. Rubber bumpers shall be provided to cushion door closing.

• Doors shall be fabricated of furniture grade red oak plywood, covered by red oak veneer, and finished with a 3-coat lacquer finish.

• All doors shall include a 16 gauge continuous piano hinge fastened to the door with screws and riveted to the frame. - SKU: HLWL5580
