Fusion 010-02199-00 Xs-f40cwb 4" Speaker

Garmin Fusion XS Series Marine Speakers
Brand New Includes One Year Warranty

The Garmin XS Series Marine Speakers deliver high-performance acoustics, enhanced protection from the environment and multi-color RGB LED lighting. It features a high-resolution low-frequency acoustics with Polypropylene Cone Technology. The XS Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog, temperature, vibration, and UV. The aluminum dome tweeter provides smooth upper-frequency response and increased efficiency, which delivers crystal-clear music reproduction. The overhung design reduces distortion and increases power and efficiency to deliver a truly high-quality sound experience. It is build up with an open basket construction allows for extended power handling and versatile mounting options with reduced mounting depth. It has a provide bright and even LED illumination in a wide range of colors.

XS Series Marine Speakers Features:

• XS Series Marine Speakers
• 4 Ohm Impedance
• Polypropylene Cone Technology
• True-Marine Design
• Aluminum Dome Tweeter
• Designed to Comply with ISO12216
• Overhung Voice Coil
• Fully Sealed Crossover Components
• Open Basket Construction
• Multi-color RGB LED Lighting
• IP65 Rated

GENERAL:

• Physical dimensions (Diameter x Depth):
  - 7.7" Classic: 7.72" x 3.70" (196 x 94 mm)
  - 7.7" Sports: 7.72" x 3.82" (196 x 97 mm)
  - 6.5" Classic: 6.97" x 3.19" (177 x 81 mm)
  - 6.5" Sports: 6.97" x 3.27" (177 x 83 mm)
  - 4" Classic: 5.31" x 2.68" (135 x 68 mm)
• Water and dust rating: IP65
• Configuration: Coaxial
• Speaker size:
  - XS-F77CWB / XS-FL77SPGW / XS-F77SPGW: 7.7"
  - XS-F65CWB / XS-FL65SPGW / XS-F65SPGW: 6.5"
  - XS-F40CWB: 4"
• Peak power (Watts)
  - 7.7" Speaker: 240 W
  - 6.5" Speaker: 200 W
  - 4" Speaker: 120 W
• RMS power (Watts)
  - 7.7" Speaker: 60 W
  - 6.5" Speaker: 50 W
  - 4" Speaker: 30 W
• Sensitivity (1 W / 1 m)
  - 7.7" Speaker: 92 dB
  - 6.5" Speaker: 91 dB
  - 4" Speaker: 87 dB
• Frequency response
  - 7.7" Speaker: 70 Hz-18 kHz
  - 6.5" Speaker: 80 Hz-18 kHz
  - 4" Speaker: 100 Hz-18 kHz
• Nominal impedance: 4 ohms
• Recommended amplifier power (RMS)
  - 7.7" Speaker: 25-200 W/Ch
  - 6.5" Speaker: 20-150 W/Ch
  - 4" Speaker: 15-80 W/Ch
• LED lighting: Yes (RGB; sports-style only)
• LED Supply Voltage: 10.8-16 VDC (sports-style only)
• LED load current
