CyberPower MBP63A2 208 VAC 63A Maintenance Bypass UPS (MBP63A2)

Technical Information

PDU Type: Maintenance Bypass
Plug/Connector Type: Hardwire Terminal Block
Plug/Connector Detail: 1 x Hardwire Terminal Block
Receptacle Type: NEMA L6-20R, NEMA L6-30R, Hardwire Terminal Block
Receptacle Detail: 1 x NEMA L6-20R, 1 x NEMA L6-30R, 1 x Hardwire Terminal Block
Features: LED Status Indicator

Power Description

Input Voltage: 230 V AC
Input Voltage Range: 200 V AC - 240 V AC
Output Voltage: 208 V AC
Input Current: 63 A

Physical Characteristics

Mounting Orientation: Horizontal/Vertical
Mount Type: Rack-mountable, Wall-mountable
Form Factor: Rack/Tower
Rack Height: 2U
Cord Length: 3.30 ft
Height: 3.4"
Width: 17"
Depth: 4.9"
Weight (Approximate): 8.80 lb

Environmental Conditions

Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Minimum Storage Temperature: -4°F (-20°C)
Maximum Storage Temperature: 113°F (45°C)

Miscellaneous

Package Contents:

• MBP63A2
• UPS Mounting Hardware

Additional Information:

Physical Dimensions - (WxHxD) (cm) : 43.18 x 8.64 x 12.45 (cm)

Physical Dimensions - (WxHxD) (in) : 17 x 3.4 x 4.9 (in)

Physical Dimensions - (WxHxD) (mm) : 432 x 86 x 124 (mm)

Weight (kg) : 3.99

Weight (lb) : 8.8

Shipping Dimensions - (WxHxD) (cm) : 52.07 x 18.03 x 45.21 (cm)

Shipping - Dimensions (WxHxD, in) : 20.5 x 7.1 x 17.8 (in)

Shipping - Dimensions (WxHxD, mm) : 520.7 x 180.34 x 452.12 (mm)

Shipping - Weight (kg) : 7.48

Shipping - Weight (lb) : 16.5

Cord Length : 3.3 ft (1.0 m)

Inlet To UPS Input : (1) Terminal Block

Inlet To UPS Output : (1) Terminal Block

Inlet To Utility Power : (1) Terminal Block

Input Plug Type : Hardwire

Input Voltage Range : 200 VAC - 240 VAC

Maximum Input Current : 63A

Nominal Output Voltage : 208 VAC

Number of Outlets : 3

Outlets - Total : 3

Outlet Type COMPUTED : 1 - NEMA L6-20R

Overload Protection : None

USB Charge Port : No

Management Cable : MBP Detection Cable 3.3 ft.

Form Factor : Rack / Tower

Form Factors Supported : 2U Rackmount

Material of Construction : Metal

Rack Height : 2U

Operating Elevation : 0 - 10000 ft (0 - 3048 m)

Operating Relative Humidity : 0 - 90 % (non-condensing)

Operating Temperature : 32 - 104 °F (0 - 40 °C)

Storage Elevation : 0 - 50000 ft (0 - 15239 m)

Storage Temperature : -4 - 113 °F (-20 - 45 °C)

UPS Models : OL5KRTHD, OL6KRTHD, OL5KRTHDL, OL6KRTHDL, OL8KRTHD, OL10KRTHD, OL6KRT, OL8KRT, OL10KRT

Environmental : RoHS Compliant

Safety : UL 1778

Extended Warranty Option : WEXT5YR-ACC2B

Product Warranty : 3 Year Limited Warranty

Application/Usage: UPS, Data Center, IT Equipment, Server
Compatibility:

CyberPower Smart App Online UPS:

• OL5KRTHD
• OL6KRTHD
• OL5KRTHD
• OL6KRTHD
• OL5KRTHDL
• OL6KRTHDL
• OL8KRTHD
• OL10KRTHD
• OL6KRT
• OL8KRT
• OL10KRT

Certifications & Standards: UL 1778
Country of Origin: China
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
UL Listed: Yes

Warranty

Limited Warranty: 3 Year
