Eastwood Versa Cut 2X2 CNC Plasma Cutting Table

The Eastwood Versa-Cut 2' X 2' CNC Plasma Table packs features of a professional CNC Plasma Table in a footprint suited for your home garage. The 24" x 24" cut area is great for custom brackets, sign art, and making generic shapes rapidly. Its lead screw driven design allows ±0.2mm accuracy of movement from the X & Y-axis stepper motors and combines with Automatic Torch Height Control for clean, accurate cuts. The CNC Cut Controller operates fully independent of a PC and enables you to dimension and cut fifty pre-loaded shapes. Additionally, any CAD file post-processed in Autodesk® Fusion 360® can be loaded via USB Drive and modified as needed by the CNC Cut Controller. Limit Switches prevent machine limit collision, and the included Waterbed prevents heat soak, warping, and reduces spark & fume hazards. The CNC Cut Controller with Torch Height Control, Limit Switches, and Waterbed, features frequently unavailable, or only offered at an additional cost by competing units focused on home shop use, are all included with the Eastwood Versa-Cut 2’ X 2’ CNC Plasma Table.

This requires a plasma cutter that must be purchased separately and not included with the table.

Plasma Table Power Requirements: 120±10% VAC, 50/60 Hz, 5A
Plate Capacity: 24-in. x 36-in. x 0.25-in. thick
Weight Capacity (Includes workpiece and full Waterbed): 200 lbs. (90kg)
Waterbed Fluid Capacity: 10.4 gal (39.4L)
CNC Torch Travel X-Axis: 24.0-in. (610mm)
CNC Torch Travel Y-Axis: 24.0-in. (610mm)
CNC Torch Travel Z-Axis: 1.96-in. (50mm)
Assembled Waterbed Dimensions X-Axis: 27.75-in. (705mm)
Assembled Waterbed Dimensions Y-Axis: 40.06-in. (1018mm)
Assembled Waterbed Dimensions Z-Axis: 2.17-in. (55mm)
Overall Assembled Dimensions (W x D x H): 52.5-in. (1333mm) x 55.0-in. (1397mm) x 60.5-in. (1536mm)
Overall Assembled Unit Weight: 158.7 lbs. (72kg)
Movement Accuracy: ±0.2mm
Cutting Accuracy: ±0.5mm
