Eastwood 200 Amp Elite MP200i Multi Process Welder MIG - TIG - Stick

Everyone who owns an MP200i Eastwood welder can fabricate metal like a professional in their home shop. This multi-process welder from the Eastwood Elite series is designed to do it all. It includes pro-grade torches for MIG, TIG and stick welding that use common consumables. You can do wire-free flux core welding, too. They aren’t stripped-down torches, either — each of these processes has all the same capabilities and features as you would find in a standalone welder. The 200-amp output is enough to weld up to 3/8-inch thick steel, and with an Eastwood Spool Gun you can weld aluminum, too!

The R&D guys have made it possible to customize your 3-in-1 welder for every job. It has infinitely adjustable knobs, digital displays, a built-in spot weld timer and heavy-duty wire feed motor. By using the latest IGBT inverter technology, we’ve slimmed the welder down to just 34 pounds for portability. We’ve included all the supplies you need to get started, included a shielding gas hose, welding rods, gas nozzles and ray tungsten. Eastwood Elite welders have a 3-year manufacturer’s warranty and lifetime tech support.

Specifications

Input power: VAC 120-230
Frequency: 50/60 Hz
Rated input current: 20 Amps 120 VAC - 36 Amps 230 VAC
Rated working voltage: 18.5 volts @ 120 VAC - 24 volts @ 230 VAC
MIG welding current: 30-90 A @ 120 VAC | 30-200 A @ 230 VAC
TIG welding current: 20-90 A @ 120 VAC | 20-200 A @ 230 VAC
Stick welding current: 30-70 A @ 120 VAC | 30-170 A @ 230 VAC
Rated duty cycle: 120 VAC 40% @ 90A - 230 VAC 20% @ 200A
Weight: 34 lbs.
Warranty: 3 Years

Contents

(1) MP200i Dual-Voltage, Multi-Process Welder
(1) Adapter Cord, 12 Ga., 3’ [0.91m], 120Volt 30 Amp Plug/NEMA 50R Receptacle
(1) Shielding Gas Regulator
(1) Shielding Gas Hose, 4.6’ [1.4m]
(1) Ground Clamp with 10’ [3m] Cable
(1) Trafimet ERGOPLUS 24, Tweeco Style MIG Torch. 10’ Length. (0 .030”/0.8mm contact tip installed)
(5) Spare 0.030 Contact Tips
(1) Electrode Holder with 12.5’ [3.8m] Cable
(1) WP-17v TIG Torch with 10’ [3m] cable, 14’ [4.3m] Gas Line
(1) #4 Gas Nozzle (1/4”)
(1) #5 Gas Nozzle (5/16”)
(1) #6 Gas Nozzle (3/8”) (Installed)
(1) Short Black Cap (Installed)
(1) Long Black Cap
(1) Collet Body, 1/8” [3.2mm] (Installed)
(1) Collet, 1/16” [1.6mm] (Installed)
(1) Collet, 1/16” [1.0mm]
(1) Collet, 1/16” [2.0mm]
(1) 1/16” x 6” Tungsten (Gray)
(1) Welding Wire Spool, 2lb., 0.030” Solid Wire
(5) Welding Rods, 1/8” E6013

Spool Gun for welding aluminum is optional and not included.
