Hero image 0 of CyberPower PDU44003 Single Phase 100 120 VAC 30A Switched ATS PDU, 0 of 4

CyberPower PDU44003 Single Phase 100 120 VAC 30A Switched ATS PDU

(No ratings yet)

Key item features

Redundant Power: Ensures continuous operation of critical devices by automatically switching to a secondary power source if the primary source fails or exceeds thresholds, with a quick transfer time of less than 10 ms.
Advanced Monitoring: Offers real-time local and remote monitoring capabilities, including a built-in web interface, power event notifications, and an LCD with selectable background color.
Flexible Outlets: Features 17 outlets, comprising 16 NEMA 5-20R and 1 NEMA L5-30R, supporting input voltages between 100-120V AC and an input current of 30A.
Remote Management: Provides controllable receptacles with power sequencing and remote outlet switching, supporting various management protocols like IPv4, SNMPv3, HTTPs, and SSH.
Durable Construction: Constructed with a black metal chassis, designed for 2U rack-mountable horizontal installation, and includes a cord retention tray for cable management.
Broad Compatibility: Suitable for data centers and network closets, certified by UL62368 via cTUVus and FCC Class A, and is RoHS compliant.

Generated by AI

Specs

Outlets
17
Mount type
Rack Mount
Orientation
Horizontal
Size
2U
Volts
120 V
Watts
30 Watts

Current price is $990.95

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Columbus, 43215

Arrives by Fri, Feb 20

Sold and shipped by PCNation Customer Care

4.444444444444445 stars out of 5, based on 45 seller reviews(4.4)

Report an issue with this seller

Free 30-day returns

Other sellers

$1,113.00

+Free shipping

Shipping, arrives by Thu, Feb 19 to Columbus, 43215

Sold and shipped by Beach Audio Inc

Free 15-day returns

About this item

Product details

General Information

Ensure continued operation of critical devices with the CyberPower PDU44003 Switched ATS PDU. Ideal for data centers and network closets, this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds, or if power fails, the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable. Additionally, this unit offers real time remote and local monitoring and outlet management.

The PDU44003 supports inputs between 100-120V and includes (16) NEMA 5-20R and (1) L5-30R outlets. Dual NEMA L5-30P power cords are plugged into separate power sources (A and B), and information about each power source is clearly displayed on the front panel LED indicator lights. Other features include an LCD with selectable background color, built-in web interface, and power event notifications. The CyberPower PDU44003 is protected by a three-year limited warranty.

Technical Information

PDU Type:	Switched
Phase:	Single Phase
Plug/Connector Type:	NEMA L5-30P
Plug/Connector Detail:	2 x NEMA L5-30P
Receptacle Type:	NEMA 5-20R
Receptacle Type:	NEMA L5-30R
Receptacle Detail:	16 x NEMA 5-20R
Receptacle Detail:	1 x NEMA L5-30R
Protection Type:	Overload Protection
Locking Receptacles:	Cord Retention Tray
Features:	LED Status Indicator

Power Description

Input Voltage:	120 V AC
Input Voltage Range:	100 V AC - 120 V AC
Output Voltage:	100 V AC
Output Voltage:	120 V AC
Output Voltage Range:	100 V AC - 120 V AC
Input Current:	30 A
Input Frequency:	60 Hz

Management

Management:	Protocols: IPv4 TCP IP UDP SNMPv1 HTTP NTP DNS Telnet DHCP SMTP FTP IPv6 SNMPv3 HTTPs SSH SSL TLS LDAP(S) RADIUS Syslog CLI Windows AD SNMP
Remote Outlet Switching:	Yes

Interfaces/Ports

Network (RJ-45):

Yes

Physical Characteristics

Color Family:	Black
Product Color:	Black
Mounting Orientation:	Horizontal
Mount Type:	Rack-mountable
Rack Height:	2U
Cord Length:	10 ft
Height:	3.5"
Width:	17.1"
Depth:	8.4"
Weight (Approximate):	17.59 lb

Environmental Conditions

Minimum Operating Temperature:	32°F (0°C)
Maximum Operating Temperature:	113°F (45°C)
Minimum Storage Temperature:	5°F (-15°C)
Maximum Storage Temperature:	131°F (55°C)
Application/Usage:	Network Device
Application/Usage:	Data Center
Certifications & Standards:	UL62368 via cTUVus FCC Class A ICES-003: Issue 7
Country of Origin:	China
Environmentally Friendly:	Yes
Environmental Compliance:	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty:

3 Year

Miscellaneous

Additional Information:

Physical Dimensions - (WxHxD) (cm) : 43.31 x 8.89 x 21.46 (cm)

Physical Dimensions - (WxHxD) (in) : 17.05 x 3.5 x 8.45 (in)

Physical Dimensions - (WxHxD) (mm) : 433 x 89 x 215 (mm)

Weight (kg) : 7.98

Weight (lb) : 17.6

Shipping Dimensions - (WxHxD) (cm) : 54.61 x 17.78 x 40.32 (cm)

Shipping - Dimensions (WxHxD, in) : 21.5 x 7 x 15.875 (in)

Shipping - Dimensions (WxHxD, mm) : 546.1 x 177.8 x 403.23 (mm)

Shipping - Weight (kg) : 9.34

Shipping - Weight (lb) : 20.6

Cord Length : 10 ft (3.0 m)

Derated Input Current : 24 A

Input Frequency Range : 50 Hz - 60 Hz

Input Plug Type : 2 x NEMA L5-30P

Maximum Input Current : 30A

Nominal Input Voltage : 100 - 120 VAC

Phase : Single Phase

Plug Style : Straight

Nominal Output Voltage : 100 - 120 VAC

Outlet Banks : 2

Outlets - Total : 17

Outlet Type COMPUTED : 16 - NEMA 5-20R

Overload Protection : 20A x 2

Power Source Transfer Time : 2-7 ms

Source Failure Detection Time : 2-3 ms

Total Transfer Time : <10 ms

Environmental Sensor : Optional, via RJ45

Hardware Connection Port : Ethernet (RJ45)

LCD : Multifunction LCD

LED Indicators : Source Status

Modular Expandability (Cascading) : Yes, via RJ45

Outlet switching : Yes

SNMP / HTTP Remote Monitoring : IPv4, TCP/IP, UDP, SNMPv1, HTTP, NTP, DNS, Telnet, DHCP, SMTP, FTP, IPv6, SNMPv3, HTTPs, SSH, SSL, TLS, LDAP(S), RADIUS, Syslog, CLI, Windows AD

Upgradeable firmware : Yes

Color : Black

Cord Retention Tray/Cord Organizers : Yes

External Site Ground Pin : Yes

Form Factors Supported : 2U Rackmount

Material of Construction : Metal

Rack Height : 2U

Style : Rackmount

Operating Elevation : 0 - 13123 ft (0 - 4000 m)

Operating Relative Humidity : 0 - 95 % (non-condensing)

Operating Temperature : 32 - 113 °F (0 - 45 °C)

Storage Elevation : 0 - 49213 ft (0 - 14999 m)

Storage Temperature : 5 - 131 °F (-15 - 55 °C)

Environmental : RoHS Compliant

Safety : UL62368 via cTUVus

Extended Warranty Option : WEXT5YR-PDU1B

Product Warranty : 3 Year Limited Warranty

Real-time Local/Remote Monitoring and Switching
Controllable Receptacles with Power Sequencing
Dual Inputs
Quick Transfer Time (Total< 10 ms)
