Hero image 0 of Dayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W, 0 of 6

Dayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W

(No ratings yet)

Key item features

Item Type: Recessed Electric Wall-Mount Heater
Brand: DAYTON
Manufacturer Part Number: 3UF63
Electric Heater Item: Electric Wall Heater
Electric Heater Type: Commercial/Industrial
Watts: 3600/4800
BtuH: 12,287/16,382
Heater Voltage: 240/277VAC
Electric Heater Phase: 1
Wall Opening Width: 14-5/8"
Color: White
Amps AC: 15.0/17.2
Wall Opening Depth: 3-7/8"
Mounting Type: Recessed or Surface
Features: Double Pole Single Throw Disconnect Switch, Impedance Protected, Permanently Lubricated Totally Enclosed Motor, Thermostat with 40 to 90 Range, Thermal Overheat Protector
Grille Depth: 1 1/2 in
Housing Depth: 3 3/4 in
Standards: UL Listed
Item: Recessed Electric Wall-Mount Heater
Grille Material: Steel
Grille Height: 19 1/4 in
Housing Height: 18 1/4 in
Hz: 60
Housing Width: 14 5/16 in
Wall Opening Height: 18-1/4"
Manufacturers Warranty Length: 5 yr On Element, 1 yr All other parts
Finish: Powder Paint
Grille Width: 15 3/4 in
Air Temp. Rise: 132 Degrees F
Voltage: 240/277V AC
Air Flow: 100 cfm
Phase: 1
Includes: Built-in Thermal Cutout, Fan Delay Switch
Automatic Fan Delay (On/Off): Yes
Tamper Resistant: No
Minimum Mounting Height from Floor: 8 in
Disconnect Switch: Yes
Hold Function: No
Control Type: Mechanical Selector Dial
Rough-In Dimensions - H x W x D: 18-1/4 in x 14-5/8 in x 3-7/8 in
Rough-In Height: 18 1/4 in
Occupancy Sensor: No
Programming Capability: Not Programmable
Fan Only Operation: Yes
Grille Finish: Powder Coated
Setback Control: No
Building Management System Compatible: No
Frequency: 60 Hz
Wattage Output: 3,600W/4,800W
Wattage Field Convertible: Yes
Heating Capacity: 12,287/16,382 BtuH
Thermostat Contact Type: Double Pole
Grille Color: White
Heating Method: Fan Forced
Remote Control Functions: No Remote Control Included
Thermostat Included: Unit-Mounted
Minimum Mounting Distance from Ceiling: 36 in
Amperage: 15A/17.2A
Smart Connectivity: No Connectivity
Rough-In Width: 14 5/8 in
Voltage, Phase: 240/277V AC, 1-phase
Thermal Overheat Protection: Manual Reset
Housing Material: Steel
Filter Included: No
Heater Mounting Position: Horizontal Burn
Rough-In Depth: 3 7/8 in

Specs

Fuel type
Electric
Space heater type
Wall Heaters
Power type
Corded Electric
Brand
Dayton
Rec location
Indoor
Watts
3600 Watts

Current price is Now $382.03

You save $42.30

was $424.33

Price when purchased online

Free shipping
Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $36.00

4-Year Plan - $49.00

How do you want your item?

Columbus, 43215

Arrives by Thu, Feb 12

Sold and shipped by SIM Supply Inc

4.332020547945206 stars out of 5, based on 5840 seller reviews(4.3)

Report an issue with this seller

Free 30-day returns

Compare with similar items

Comparison Overview:
Product	Viewing this item Dayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W current price Now $382.03, Was $424.33 Dayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W	Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8 current price $394.11 Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8	Recessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White current price $404.11 Recessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White	Dayton Electric Ceiling Heater,240VAC,750W CP752F current price $465.36 Dayton Electric Ceiling Heater,240VAC,750W CP752F	Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2 current price Now $407.15, Was $448.99 Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2	Dayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7 current price $333.18 Dayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7	Open Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70 current price $286.99 Open Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70	Dayton Electric Radiant Cove Heater,1050W,240V 3UH03 current price $412.45 Dayton Electric Radiant Cove Heater,1050W,240V 3UH03	DAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface current price $314.04 DAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface 3.3 out of 5 Stars. 4 reviews	Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187 current price Now $412.44, Was $454.99 Dayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187

Comparison Chart:
Fuel type	ElectricDayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8	ElectricRecessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White	-Dayton Electric Ceiling Heater,240VAC,750W CP752F	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2	ElectricDayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7	ElectricOpen Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70	ElectricDayton Electric Radiant Cove Heater,1050W,240V 3UH03	ElectricDAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187
Space heater type	Wall HeatersDayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W	Fan-Forced HeatersDayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8	Wall HeatersRecessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White	Radiant HeatersDayton Electric Ceiling Heater,240VAC,750W CP752F	Fan-Forced HeatersDayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2	Fan-Forced HeatersDayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7	Wall HeatersOpen Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70	Radiant HeatersDayton Electric Radiant Cove Heater,1050W,240V 3UH03	Panel HeatersDAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface	Fan-Forced HeatersDayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187
Power type	Corded ElectricDayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8	ElectricRecessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White	Corded ElectricDayton Electric Ceiling Heater,240VAC,750W CP752F	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2	ElectricDayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7	ElectricOpen Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70	ElectricDayton Electric Radiant Cove Heater,1050W,240V 3UH03	Corded ElectricDAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface	ElectricDayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187
Rec location	IndoorDayton 3UF63 Recessed Electric Wall-Mount Heater Recessed or Surface 3600/4800 W	IndoorDayton Lg Recssd Elct Wl Heatr,18-1/4" H,120V 2HAD8	IndoorRecessed Electric Wall-Mount Heater, Recessed or Surface, 1500 W, 120V AC, White	IndoorDayton Electric Ceiling Heater,240VAC,750W CP752F	IndoorDayton Lg Recssd Elct Wl Heatr,18-1/4" H,240V 3END2	IndoorDayton Cmpct Recssd Elct Wl Heatr,11-1/4"H,120V 3ENC7	IndoorOpen Box Dayton Cmpct Recssd Elct Wl Heatr,12-5/8"H,240V 5ZK70	IndoorDayton Electric Radiant Cove Heater,1050W,240V 3UH03	IndoorDAYTON 5ZK68 Recessed Electric Wall-Mount Heater, Shallow Recessed or Surface	IndoorDayton Lg Recssd Elct Wl Heatr,18-1/4" H,277V 5E187

Now hiding additional rows in the Table

About this item

Product details

Recessed Electric Wall-Mount Heater, Commercial/Industrial, 3600/4800 Watts, 12,287/16,382 BtuH, Heater Voltage 240/277 V AC, Electric Heater Phase 1, Wall Opening Width 14-5/8 In., Color White, 15.0/17.2 Amps AC, Wall Opening Depth 3-7/8 In., Wall Opening Height 18-1/4 In., Mounting Type Surface and Recessed, 60 Hz, Air Temp. Rise 132 Degrees F, Grille Material Steel, Grille Width 15 3/4 in, Grille Depth 1 1/2 in, Grille Height 19 1/4 in, Housing Width 14 5/16 in, Housing Depth 3 3/4 in

Item Type: Recessed Electric Wall-Mount Heater
Brand: DAYTON
Manufacturer Part Number: 3UF63
Electric Heater Item: Electric Wall Heater
Electric Heater Type: Commercial/Industrial
Watts: 3600/4800
BtuH: 12,287/16,382
Heater Voltage: 240/277VAC
Electric Heater Phase: 1
Wall Opening Width: 14-5/8"
Color: White
Amps AC: 15.0/17.2
Wall Opening Depth: 3-7/8"
Mounting Type: Recessed or Surface
Features: Double Pole Single Throw Disconnect Switch, Impedance Protected, Permanently Lubricated Totally Enclosed Motor, Thermostat with 40 to 90 Range, Thermal Overheat Protector
Grille Depth: 1 1/2 in
Housing Depth: 3 3/4 in
Standards: UL Listed
Item: Recessed Electric Wall-Mount Heater
Grille Material: Steel
Grille Height: 19 1/4 in
Housing Height: 18 1/4 in
Hz: 60
Housing Width: 14 5/16 in
Wall Opening Height: 18-1/4"
Manufacturers Warranty Length: 5 yr On Element, 1 yr All other parts
Finish: Powder Paint
Grille Width: 15 3/4 in
Air Temp. Rise: 132 Degrees F
Voltage: 240/277V AC
Air Flow: 100 cfm
Phase: 1
Includes: Built-in Thermal Cutout, Fan Delay Switch
Automatic Fan Delay (On/Off): Yes
Tamper Resistant: No
Minimum Mounting Height from Floor: 8 in
Disconnect Switch: Yes
Hold Function: No
Control Type: Mechanical Selector Dial
Rough-In Dimensions - H x W x D: 18-1/4 in x 14-5/8 in x 3-7/8 in
Rough-In Height: 18 1/4 in
Occupancy Sensor: No
Programming Capability: Not Programmable
Fan Only Operation: Yes
Grille Finish: Powder Coated
Setback Control: No
Building Management System Compatible: No
Frequency: 60 Hz
Wattage Output: 3,600W/4,800W
Wattage Field Convertible: Yes
Heating Capacity: 12,287/16,382 BtuH
Thermostat Contact Type: Double Pole
Grille Color: White
Heating Method: Fan Forced
Remote Control Functions: No Remote Control Included
Thermostat Included: Unit-Mounted
Minimum Mounting Distance from Ceiling: 36 in
Amperage: 15A/17.2A
Smart Connectivity: No Connectivity
Rough-In Width: 14 5/8 in
Voltage, Phase: 240/277V AC, 1-phase
Thermal Overheat Protection: Manual Reset
Housing Material: Steel
Filter Included: No
Heater Mounting Position: Horizontal Burn
Rough-In Depth: 3 7/8 in
