Commercial Motor Electric Oil Pump Self Priming Transfer Pump 16GPM 110V 550W US

Description

The electric oil pump with a portable handle can make it easier for you to take it to the workplace. The powerful power of 550W can help you finish your work quickly and well. It is a "self-priming" electric oil pump, which means you do not need to fill the water pump before the first use. It will be a good helper for enterprises, mines, construction sites, fishing boats, pleasure boats, and small refueling points.

Specifications

6.15ft Power Cord: The 6.15ft long power cord can reduce the space distance limitation for you to place the device, allowing you to use it more freely.

Stable Base: The outward extending base is very stable and can guarantee the machine will not shake during operation.

Multi-layer Oil Seal: The multi-layer oil seal ring can lock the liquid very well, thus guaranteeing the machine works dryly.

Thickened Cast Iron Pump Head: The thickened cast iron construction makes it have higher working strength, so it is ideal for fieldwork.

Rubber Antifouling Dust Plug: With a special rubber antifouling dust plug, it can effectively block dust and dirt to avoid damage to the inside of the machine.

Application

The applicable medium of this product is diesel oil and kerosene. It is mainly used for refueling mining machinery, engineering machinery, construction sites, fishing boats, cruise ships, small refueling points, and other equipment, as well as refueling and transmission of automobile self-provided power supply.

Specification

Model: ACTP60

Process: Painting

Color: Yellow, Silver, Black

Material: Cast Iron, Aluminum Alloy, Copper

Plug Standard: US Standard

Motor: AC 110V 60Hz

Flow Rate: 20-60L/5.28-15.85gal/min

Power: 550Watts Self Priming

Max. Speed: 3300rpm

Suction Height: 5m/16ft

Max Lift: 15m/49ft

Inlet and Outlet Size: 2.5cm/1in

Power Cord Length: 1.88m/6.16ft

Maximum Working Pressure: 3Bar

Accuracy of Flowmeter: ± 1%

Single Counting Range: 0 ～ 9999L/0 ～ 2641.46Gal (4-digit Liter, Maximum 9999L/2641.46Gal, Last 1-digit Liter with Scale)

Assembly Required: Yes

Product Size:  30*20*20cm/ 11.8*7.9*7.9 in

Package Included

1 * Electric Oil Pump Transfer Fuel Diesel

1 * English Manual

1 * Filter

2 * Connectors

Notes

The motor of this product is ordinary and not explosion-proof. Therefore, it is strictly prohibited to use gasoline and high ignition point media!
 Please read the operating manual completely before use. And pay particular attention to the safety instructions included.
3.  Our oil pump will be tested with diesel oil before leaving the factory, so some of the diesel remains in the machine, please use it after cleaning.

4. It is not allowed to transport gasoline, ethanol, non-ethanol, and second-cycle fuel.

5. Please make sure the power supply and oil pump voltage match before use.

6. The oil inlet pipe and joints must not leak to ensure the suction range.

7. Remember to install a strainer in the oil inlet pipe to avoid damage to the pump core due to hard debris being sucked into the pump cavity. The vane should always clear the surface dirt of the screen, otherwise, the screen will be blocked and the flow will be reduced and the pump will be damaged.

8. The oil pump can work continuously, but idling without oil should not exceed 5 minutes, so as not to damage the pump core, oil seal, and vane by friction and heat.

9. In order to ensure the service life of the oil pump, it is recommended to stop the pump after 20 minutes of continuous work for a short break.
