Carbon XT MTB Bike Pedal Self-Locking SPDING Pedal Mountain Bike Clipless Pedals With Cleats DU Bearing M8100 Bicycle Pedals

RACEWORK Pedals X-M8100 Race Carbon MTB

The newly developed RACEWORK Pedals X-M8100 pedals convince with their outstanding ratio of footprint to weight. The sole of the shoe rests on an area of 515 mm² on the 60 millimeter wide pedals, which ensures an optimal grip on the pedal and prevents unwanted play. This significantly reduces power loss when pedaling, especially for hard starts and sprints. The large contact area also makes it easier to get into the pedal, since the surface offers good guidance even when clicked out.

The two-sided click mechanism of the RACEWORK Pedals X-M8100 pedals works even in the most adverse conditions. The Chromoly steel platform is designed so that it has very good self-cleaning in muddy conditions. The release hardness of the pedals can be easily adjusted between 6 and 10 Newton meters using an Allen screw for individual needs. Due to the compact design of the pedals, they are extremely robust and can easily withstand occasional patches. Despite their robustness and large contact area, the weight remains relatively low thanks to the carbon base.  30% CARBON  and  70% injection process The click mechanism is compatible with all Shiman SPDING (MTB) cleats.

Technical specifications:

Intended intended use : MTB, cyclocross, gravel bike

Pedal axle material: Chromoly steel

Pedal body material: 30% carbon, 70% injection process

Footprint material: Chromoly steel

Footprint size: 515 mm²

Bearings: sealed industrial bearings

Freedom of movement: +/- 6 °

Trigger hardness: 6 - 14 Nm continuously adjustable

Release angle: not specified

Q factor: adjustable by pedal plates by approx. 2 mm

Compatibility For SHIMAN SPDING sole standard

Weight restriction: not specified

Colors: black

Weights (manufacturer information): 348g (pedals only), 444g (incl.cleats)

Scope of delivery: 1x pair of RACEWORK Pedals X-M8100  Race carbon pedals, cleats, mounting screws
