Eastwood 140 Amp Elite MP140i Multi Process Welder MIG - TIG -Stick

The Eastwood TIG 200DC is designed for the enthusiast wanting the benefits of TIG welding steel and stainless without the cost of an AC inverter. The TIG200DC is one of the easiest TIGs on the market for set up and use and also includes the most features. A must for anyone wanting to get started in TIG welding!

Whether you’re new to welding or work as a professional, the Eastwood MP140i is an all-in-one welder that will Do the Job Right. This multi-process welder can do MIG, TIG, flux core or stick welding for your custom body panels and parts. It has a 140-amp output capable of joining sheet metal and steel up to 3/16-inch thick. Add the optional Spool Gun to weld aluminum. Some of the useful features include a spot weld timer for panel-hanging, infinitely adjustable knobs for precise tuning and a digital display to give you accurate readings.

Those who order the Eastwood Elite 140-Amp Multi-Process Welder receive a rugged machine with three pro-grade torches plus common consumables and accessories. It weighs a mere 34 pounds, meaning you can bring it anywhere a welding job is needed. And the unit runs off a standard 120V power output! Eastwood is a pioneer in DIY welding who offers high-quality machines with a 3-year warranty. If you need a little extra punch, check out the MP200i welder for 3/8-inch metal.

Specifications

Input power: VAC 120
Frequency: 50/60 Hz
Rated input current: 20 Amps
No-load voltage: 68 volts
Rated working voltage: 18.5 volts
MIG welding current: 30～140 A
TIG welding current: 20～90 A
Stick welding current: 30～70 A
Rated duty cycle: 30% @90A
Weight: 34 lbs.
Warranty: 3 Years

Contents

(1) - MP140i Dual-Voltage, Multi-Process Welder
(1) Shielding Gas Regulator
(1) Shielding Gas Hose, 4.6’ [1.4m]
(1) Ground Clamp with 10’ [3m] Cable
(1) Trafimet ERGOPLUS 15, Tweeco Style MIG Torch. 10’ Length. (0 .023”/0.6mm contact tip installed)
(5) Spare 0.023” [0.6mm] Contact Tips
(1) Electrode Holder with 12.5’ [3.8m] Cable
(1) TIG Torch with 10’ [3m] cable, 14’ [4.3m] Gas Line
(1) #4 Gas Nozzle (1/4”)
(1) #5 Gas Nozzle (5/16”)
(1) #6 Gas Nozzle (3/8”) (Installed)
(1) Short Black Cap (Installed)
(1) Long Black Cap
(1) Collet Body, 1/8” [3.2mm] (Installed)
(1) Collet, [1.6mm] (Installed)
(1) Collet, [1.0mm]
(1) Collet, [2.0mm]
(1) 1/16” x 6” Tungsten (Gray)
(1) Welding Wire Spool, 2lb., 0.023” Solid Wire
(5) Welding Rods, 1/8” E6013

Spool Gun for welding aluminum is optional and not included.
