Amzgachfktch 4 Burners 24 inch Gas Cooktop Stainless Tempered Glass Natural Gas/LPG Convertible

Black Tempered Glass Panel

Cast Iron Burner Cap And Grate

Heat-Resistant Aluminum Burner

Melt-Proof Bakelite Knob

Thermocouple Protection

4 High Powerful Burners

Automatic Pot Detection

Automatic Electrc Pulse Ignition

Cast Iron Grate Has Unique 4-Claw Structure:Suitable For Almost All Sizes Of Pots

NG/LPG Convertible

Details:

Cut out Dimensions:21.73" Wx 18.5" L

Installation:Built-In/Integrated

Number of Burners:4

Control Design:Knob Control

Color:Black

Material:Tempered Glass

Product Dimensions:22.99" W x 20.08" L x 3.93"H

Item Depth:20 in

Fuel Type:Dual Fuel

Surface:Burner

Brand:Amzgachfktch

Design:Cooktop

Type:Gas Cooker

Manufacturer Warranty:2 Year Part Warranty

Item Height:3.9 in

Model:GH003-244G

Features:Easy Clean, Front Control

Power Requirement:120 V

Country/Region of Manufacture:China

Item Width:24 in

Pan Support Material:Heavy-Duty Cast Iron

Control Type: Bakelite Knobs Control

Ignition Type: Electronic pulse ignition

Voltage: 110V, 3-prong plug

Cable Length: 4.5 Feet

Installation Type: Built-in

Please note that:

1) Extra LPG Nozzles included in the package, the natural gas pressure regulator and the gas pipe are NOT included.

2)It is recommended that gas stove be installed and tested by professionals.

Old-style cooktops usually use plastic at the back side, which is easy to be damaged by aging. Back sides of our gas cooktop is made of stainless steel, it is stronger, more anti-wear and safer and has a longer service life.

 Installation of built-in gas cooktop

This gas cooktop is for bulit-in use only, please verify the gas cooktop is the right size for you.

Product Dimensions: 22.99" W x 20.08" L x 3.93"H

Cut out Dimensions: 21.73" Wx 18.5" L

For a correct installation, the following precautions must be followed:

a) Fixing fittings (brackets, screws) are provided to place the gas cooktop on work top, measure 0.79 to 1.58 inch in thickness

b) In the event the gas cooktop is not installed on a built-in oven, a wooden panel must be inserted for insulation.This panel must be placed at least 0.79 inch distance from the bottom of cooktop.

c) When installing the gas cooktop on a built-in oven, the oven should be placed on two wooden strips; in the case of a joining cabinet surface, remember to leave a space of 1.78 x 22 inch at least from the back side.
