Skf Radial Ball Bearing,Sealed,45mm Bore Dia 6309 2RS JEM
SKF

Skf Radial Ball Bearing,Sealed,45mm Bore Dia 6309 2RS JEM

(No ratings yet)

Key item features

  • ABEC Rating:1
  • ABEC Tolerance:1
  • Ball Material:Alloy Steel
  • Bearing Industry Number:6309
  • Bearing Material:Steel
  • Bearing Type:Sealed
  • Bore Dia.:45 mm
  • Bore Diameter Tolerance:+0/-0.007 mm
  • Bore Diameter:45 mm
  • Bore Tolerance:+0/-.007mm
  • Cage Material:Steel
  • Closure:Double Sealed
  • Includes Retaining Ring:No
  • Industry Number:6309 2RS JEM
  • Item:Radial Ball Bearing
  • Lubricant Material:MT47 Grease
  • Lubrication:MT47 Grease
  • Max. RPM:9,500 RPM
  • Maximum Speed:9,500 RPM
  • Maximum Temperature:212 Degrees F
  • Minimum Temperature:-40 Degrees F
  • Number of Rows:One
  • Outer Ring Width:25 mm
  • Outside Dia. Tolerance:+0/-11 micron
  • Outside Dia.:100 mm
  • Outside Diameter Tolerance:+0/-11 micron
  • Outside Diameter:100 mm
  • Package Quantity:1
  • Seal Material:Synthetic Rubber
  • Seal Type:Contact
  • Seal/Shield Type:Double Sealed
  • Shield Material:Metal
  • Single Row/Double Row:Single Row
  • Static Load Capacity:7,100 lb
  • Static Radial Load Capacity:7,100 lbf
  • System of Measurement:Metric
  • Temp. Range:-40 Degrees to 212 Degrees F
  • Type:Sealed
  • Width:25 mm
