Grandeur 805969 Parthenon Solid Brass Sectional Single Cylinder Keyed Entry Handleset -

Single Cylinder Keyed Entry: Single cylinder handlesets are keyed on the exterior with an associated thumbturn on the inside that unlocks the door. The exterior handle has a thumb plate and the interior handle features a lever or knob. Single cylinder locks are most commonly used to secure entrances to a residence or place of business.

Features:

• Constructed of high quality brass for durability and dependability
• Installs easily with all necessary mounting hardware included
• Covered by Grandeur's limited lifetime mechanical manufacturer warranty
• Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys

Product Technologies:

• Solid Brass Construction: Grandeur rosettes and backsets are forged from a solid piece of brass. This process yields a denser, stronger and higher quality product that can better display intricate designs than cast door hardware.

Specifications:

• Backset: 2-3/8"
• Cross Bore: 2-1/8"
• Edge Bore: 1"
• Door Thickness: 1-3/4" to 2"
• Handing: Reversible Left or Right
• Latch Faceplate: Square Corner
• Cylinder: 5 Pin C
• Mounting Center to Center: 5-1/2"
• Grip Center to Center: 8-13/16"
• Overall Height: 17"
• Handle Projection: 3-5/16"
• Trim Height: 5-3/8"
• Trim Width: 2-5/8"
