BELDEN/PPC SCREW-ON MOCA PoE FILTER FOR CABLE TV & OTA INDOOR OR OUTDOOR APPLICATION - SNLP-1GCWWS

KEY FEATURES;

BELDON-PPC SNLP-1GCWWS SERIES MOCA™ PRIMARY ENTRY “PoE” FILTER.

THIS DEVICE IS INTENDED FOR INTERIOR OR EXTERIOR INSTALLATIONS APPLICATION, THE DEVICE IS WATERPROOF.

TYPICAL MOCA COAXIAL NETWORKS WILL REQUIRE ONLY ONE “PoE” FILTER INSTALLED AT THE COAXIAL CABLES’ ENTRY TO THE RESIDENTIAL DWELLING.

THIS FILTER CAN NOT BE USED IN CONJUNCTION WITH ANY SATELLITE SERVICES TRANSMITTED ON THE SAME COAXIAL CABLE. NOTE; THIS FILTER DOES NOT PASS AC/DC VOLTAGES, IF THESE ARE APPLIED THE DEVICE WILL BE DESTROYED.

BANDSTOP PROVIDES A TYPICAL -40DB OF REJECTION IN THE MoCA 1125-1525MHZ BAND. NOTE THERE IS ANOTHER MoCA "PoE" FILTERS THAT WILL PROVIDE -70DB OF MOCA BAND REJECTION IF FOUND NECESSARY.

BELDON-PPC'S MOCA FILTER IS DESIGNED TO REMOVE ANY INFERENCE THAT WOULD DISABLE THE AGC CIRCUITS OF DOSCIS 2.1 OR LOWER CABLE MODEM OPERATIONS, THE FILTER IS DOCSIS 3.0 COMPLIANT AND READY TO PROVIDE ANY SERVICES THAT WILL COME FORTH IN THE FUTURE.

THE FILTER PROVIDES INTERNAL SURGE PROTECTION RATED TO SURPASS IEEE TESTING OF 6KV B3 COMBO WAVE RESISTANCE.

DEVICES ARE DESIGNED TO REMAIN STABLE IN ENVIRONMENTS OF -40°F (-40°C) TO +140°F (+65^O C) AND MAINTAIN ALL TECHNICAL SPECIFICATIONS.

METALLIC HOUSING OF THE PROTECTOR PROVIDES EXCELLENT EMI SHIELD, EFFECTIVE BEYOND 140DB.
