Hero image 0 of Digital Manifold Gauge Refrigeration Air Pressure Gauge For Refrigerant Manifold Gauge Set, 0 of 6

Digital Manifold Gauge Refrigeration Air Pressure Gauge For Refrigerant Manifold Gauge Set

(No ratings yet)

Digital Manifold Gauge Refrigeration Air Pressure Gauge For Refrigerant Manifold Gauge Set Digital Manifold Gauge Refrigeration Air Pressure Gauge For Refrigerant Manifold Gauge Set Digital Manifold Gauge Pressure Gauge Refrigeration Vacuum Pressure Manifold Tester Leakage Monitor Detector Refrigerant Meter

Actual Color:1 set

Key item features

Specifications:
Housing material: ABS/PA/TPU
Dimensions: 265 x 135 x 75 mm/10.43 x 5.31 x 2.95"
Weight: approx. 1000 g
Parameters: pressure: kPa/MPa/bar/psi, temperature: // K.
Sensor: pressure: 2 x pressure sensor, temperature: 2 x NTC
Meas. Cycle: 0.5s
Interface pressure connection: 3 x 7/16 "UNF, NTC measurement
Measuring range:
HP/LP pressure ranges: -100 to 6000 kPa / -0.1 to 6 Mpa / -1 to 60 bar (rel) / -14.7 to 870 psi
Temperature range: -50 to + 150/ -58 to 302
Vacuum measurement range (rel) : -1 to 0 bar / -14.7 to 0 psi
Overload: 65 bar, 6500 kPa, 6.5 Mpa, 940 psi
Resolution: pressure resolution: 0.01 bar / 0.1 psi / 1 kPa / 0.001 MPa
Temperature resolution: 0.1/ 0.1
Refrigerant quantity: 60
Environmental conditions: operating temperature: -20 to 50/ -4 to 122°F
Storage temperature: -20 to 60/ -4 to 140
IP level: 42
Battery: 4 x AA (not included)
type: luminescent LCD
Response time: 0.5 seconds
Notes:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow slight measuring deviation due to manual measurement.
Package:
1 X Refrigerator Manifold Pressure Gauge Set

Specs

Display
LCD
Brand
Eugene Color
Power type
Battery
Material
ABS,PA,TPU
Color
1 set
Weight
17.65 oz

Current price is $373.33

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between May 21 - May 27

Sold and shipped by VigorMetric

3.0526315789473686 stars out of 5, based on 19 seller reviews(3.1)

Report an issue with this seller

Free 30-day returns

About this item

Product details

The pressure measured by the digtal manifold pressure tester is gauge pressure.

Pressure testing ranges from -101Kpa to 6Mpa (-0.1bar to 60bar).

The limit pressure is 10 Mpa (100 bar).

The maximum operating pressure of standard hose is 600 PSI ( approximate 4.13 Mpa, 41.3 bar ). The limit pressure is 3000 PSI approximate 20.68 Mpa, 206.8 bar ).

Do not use and store the instrument in high temperature, high humidity, flammable, explosive and strong electromagnetic fields.

Specifications:
Housing material: ABS/PA/TPU
Dimensions: 265 x 135 x 75 mm/10.43 x 5.31 x 2.95"
Weight: approx. 1000 g
Parameters: pressure: kPa/MPa/bar/psi, temperature: // K.
Sensor: pressure: 2 x pressure sensor, temperature: 2 x NTC
Meas. Cycle: 0.5s
Interface pressure connection: 3 x 7/16 "UNF, NTC measurement
Measuring range:
HP/LP pressure ranges: -100 to 6000 kPa / -0.1 to 6 Mpa / -1 to 60 bar (rel) / -14.7 to 870 psi
Temperature range: -50 to + 150/ -58 to 302
Vacuum measurement range (rel) : -1 to 0 bar / -14.7 to 0 psi
Overload: 65 bar, 6500 kPa, 6.5 Mpa, 940 psi
Resolution: pressure resolution: 0.01 bar / 0.1 psi / 1 kPa / 0.001 MPa
Temperature resolution: 0.1/ 0.1
Refrigerant quantity: 60
Environmental conditions: operating temperature: -20 to 50/ -4 to 122°F
Storage temperature: -20 to 60/ -4 to 140
IP level: 42
Battery: 4 x AA (not included)
type: luminescent LCD
Response time: 0.5 seconds
Notes:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow slight measuring deviation due to manual measurement.
Package:
1 X Refrigerator Manifold Pressure Gauge Set
