FG-200 DDS Function Signal Generator Frequency Counter 0.01Hz - 500KHz Signal Source Module Sine+Square+Sawtooth Waveform Together with an oscilloscope, it can be used for electronic circuit test and debugging, frequency characteristics and impulse response test and measurement of audio amplifiers. Due to good accuracy and frequency stability of DDS, it is also very suitable for oscilloscope time factor calibration. Have a filter (can be opened and closed) to suit output of sine and pulse . Compact size, complete functions, simple operation, easy to carry. It can be powered by a adapter or a 3.7V battery. sine , , triangle , forward sawtooth , reverse sawtooth , etc. It is especially designed for those professional worker. output is suitable for oscilloscope attenuator and probe pulse characteristic adjustment.

Specifications:
2. supply: DC4-9V, DC5V is recommended when using adapter, 3.7V battery is recommended when using battery .
10. All setup parameters can be saved.
Package Size: 15.5 * 15.5 * 5cm / 6.10 * 6.10 * 1.97in
4. Frequency : sine 0.01Hz- 500.00kHz (with further increase in frequency, output amplitude will decrease), other waveforms 0.01Hz-100.00kHz (but does not limit upper limit of adjustable frequency, if distortion and jitter requirements are not high, use of frequency can be further increased).
Item Weight: 144g / 5.07oz
7. Output amplitude: Maximum ±10V (P-P).
1. Output waveforms: sine , , triangle , forward sawtooth , reverse sawtooth , ECG , exponential rise, exponential fall, Lorentz pulse, Gauss pulse, Sinc pulse, half-, full-, Schumann , noise , and so on 15 kinds of waveforms.
Type: without Antenna / with Antenna (Optional)
9. offset: maximum ±10V, with shutdown function.
5. Resolution: 0.01Hz.
3. Current: 180MA at voltage 5V
8. output impedance: 50 ohms.
Package Weight: 325g / 11.46oz
Material: ABS
Item Size: 140 * 80 * 26mm / 5.51 * 3.15 * 1.02in
6. Sine distortion: <1% below 1kHz, <0.5% above 1kHz.
main technical parameters:
11. there are filters can be turned on and off, can be well adapted to sinusoidal and pulse waveform output.


Package List:
1 * Double-Ended BNC Cable
1 * Signal Generator
1 * USB Cable
1 * Antenna
1 * User Manual (English)
1 * BNC Clip Cable
