Creo Parametric 5.0 : Cable and Harness Design (Paperback)

As an experienced user in the basics of Creo Parametric 5.0, this learning guide enables you to create electromechanical cabling systems designed in Creo Parametric using the Piping and Cabling Extension. Utilizing the parametric and associative nature of Creo Parametric, an electromechanical designer can easily create realistic 3D cabling assemblies, wire lists, bill of material tables, and nail-board drawings. The Creo Parametric 5.0: Cable and Harness Design learning guide contains numerous practices to give you practical experience that will improve your job performance.

Topics Covered

• Cabling Process Overview
• Cabling Terminology
• Environment and Configuration Setup
• Electromechanical Model Setup
• Manual Designation and Parameters
• Manual Spools
• Manual Cabling Features
• Logical Reference Technique
• Routing Methods
• Modifying Cabling Assemblies
• Additional Routing Features
• Networking
• Cabling Assembly Deliverables
• HARNESS-MFG

  Prerequisites

  • Access to the Creo Parametric 5.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
  • We recommend that you have completed the Creo Parametric 5.0: Introduction to Solid Modeling course or have equivalent experience.
