0.56 inch LED Digital 2-line DC Voltage Table Red Blue Green DC 5-120V Voltmeter

Features:
*Use our digital voltage gauge to accurately measure voltage, 2-line design, which is convenient for wiring and reverse connection protection. Withstand voltage 132V without burning
*No external power supply -use measurement voltage as a power supply. Measurement range: DC5V-120V.
*Bright and clear LED display panel for easy reading. The automatic movement display is convenient.
*When there are a small amount of errors, the potentiometer on the circuit board is calibrated.
*High measurement accuracy, good stability, and convenient installation. This voltmeter is suitable for almost all electric vehicles
* Low start working voltage, red 5V, green 5V, blue to low 5V

Specification:
Model: DSN-DVM-568HV
Measurement range: Red DC5-120.0V, Green DC5-120.0V, Blue DC5-120.0V
Power supply scope: No need to supply a power supply, directly use the test voltage as the power supply, the range is the same as above
Maximum input: DC132V. Note: Input voltage higher than 132V may be damaged!
Allow error: ±1%;
Input impedance:> 100KΩ
Work current: red <23ma, green <18mA, blue <13ma
Refresh speed: about 300ms once
Display: Three -bit "0.56" LED digital tube
Show color: red, green, blue optional
Line length: 20cm
Dimensions: 48 x 29 x 22 mm, long x wide x thick;
Open hole size: 46 x 27mm
Net weight: 18g
Working temperature: -20℃~65℃

Package included:
1*LED voltage table

Note:
1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
