ATO 230V 7.5KW VFD Variable Frequency Drive， Single Phase Input and Output Single Phase for Spindle Motor Speed Contro

• Basics

Capacity：10 hp (7.5 kW)

Shipping weight：8 kg

Dimension：330*200*200 mm

• I/O Feature

Rated current：45 A

Input voltage：single phase AC 220V±15%

Input frequency：47~63Hz

Output voltage：0～rated input voltage

Output frequency：0~1000Hz

Over load capacity：150% of rated current for 60s, 180% of rated current for 10s, 200% of rated current for 3s

• Control Features

Start frequency：0.40Hz~20.00Hz

Speed adjustment range：1:50

Carrier frequency：1.0-16.0kHz, automatically adjusted according to temperature and load characteristics

VARIABLE FREQUENCY DRIVE：The ATO 10hp 7.5kW 49A VFD variable frequency drive features a 220V single-phase input/output, suitable for 1-phase AC motors.

ADAPTABLE DESIGN：The ATO 7.5kW 220V single-phase to single-phase VFD offers versatile usage for precise speed control, quick torque response, and consistent low-frequency output.

VERSATILE APPLICATION：The ATO 220V/230V single-phase input/output VFD is specifically designed for single-phase induction motors, making it perfect for controlling the speed of motors used in applications such as fans, pumps, mixers, extruders, slitters, winders, power tools, and more

Note: The single phase motor should not be adjusted to run based on a lower frequency than 80% of its rated frequency for along time, otherwise the motor may fail
