Johnson Controls AC Pressure Cutout Control,SPDT,Auto P20EB-1C

(No ratings yet)

Key item features

Application:High or Low Limit
Body Material Finish:Galvanized
Body Material:Steel
Capillary Length (In.):36 in
Close (PSI):70
Connection:Sweat
Contact Form:SPDT
Differential Pressure (PSI):30
Electrical Connection Type:Quick Connect Terminals
Element Type:Bellows
Enclosure:NEMA 1
Frequency:60 Hz
Function:Single
Includes:Mounting Bracket
Input Sensor Type:Pressure Sensor
Item:Pressure Cut-Out Control
Maximum Operating Temperature:140 Degrees F
Mounting:Bracket
NEMA Rating:1
Open (PSI):40 psi
Output Current:16 A
Overall Depth:2 1/4 in
Overall Height:3 3/8 in
Overall Width:2 3/8 in
Pressure Connection Size:1/4 in
Pressure Connection Type:Sweat
Pressure Connection:36 in Capillary with 1/4 in Sweat
Pressure Range - Maximum:250 psi
Pressure Range - Minimum:7 psi
Pressure Range Adjustability:Fixed
Pressure Type:Differential
Product Type:Pressure Cut-Out Control
Range (PSI):7 to 150
Rated Voltage:120V AC, 208/240V AC, 277V AC
Series:P20
Switch Action:Open on Fall
Switch Type:SPDT
Type:High/Low Pressure

Specs

Brand
Johnson Controls
Color
Multi
Accessories
Mounting Bracket
Has nrtl listing certification
N
Has written warranty
No
Dimensions
2.25 x 2.38 x 3.38 in

Current price is $126.69

Price when purchased online

Free shipping
Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

2-Year Plan - $15.00

3-Year Plan - $22.00

Smart Device Setup

Smart Thermostat Installation - $88.00

How do you want your item?

Columbus, 43215

Arrives by Sat, May 9

Sold and shipped by SIM Supply Inc

4.336085879438481 stars out of 5, based on 6055 seller reviews(4.3)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Pressure Cut-Out Control, Product Type Pressure Cut-Out Control, Pressure Range - Maximum 250 psi, Pressure Differential - Minimum Not Applicable, Pressure Range - Minimum 7 psi, Pressure Differential Max. 30 psi, Pressure Range Adjustability Fixed, Pressure Connection Type Sweat, Time Delay Setting Not Applicable, Pressure Connection Size 1/4 in, Rated Voltage 120V AC, 208/240V AC, 277V AC, Contact Form SPDT, Switch Action Open on Fall, Electrical Connection Type Quick Connect Terminals

Application:High or Low Limit
Body Material Finish:Galvanized
Body Material:Steel
Capillary Length (In.):36 in
Close (PSI):70
Connection:Sweat
Contact Form:SPDT
Differential Pressure (PSI):30
Electrical Connection Type:Quick Connect Terminals
Element Type:Bellows
Enclosure:NEMA 1
Frequency:60 Hz
Function:Single
Includes:Mounting Bracket
Input Sensor Type:Pressure Sensor
Item:Pressure Cut-Out Control
Maximum Operating Temperature:140 Degrees F
Mounting:Bracket
NEMA Rating:1
Open (PSI):40 psi
Output Current:16 A
Overall Depth:2 1/4 in
Overall Height:3 3/8 in
Overall Width:2 3/8 in
Pressure Connection Size:1/4 in
Pressure Connection Type:Sweat
Pressure Connection:36 in Capillary with 1/4 in Sweat
Pressure Range - Maximum:250 psi
Pressure Range - Minimum:7 psi
Pressure Range Adjustability:Fixed
Pressure Type:Differential
Product Type:Pressure Cut-Out Control
Range (PSI):7 to 150
Rated Voltage:120V AC, 208/240V AC, 277V AC
Series:P20
Switch Action:Open on Fall
Switch Type:SPDT
Type:High/Low Pressure
