LCR-T4 Meter Transistor Tester Diode Triode Capacitance SCR Inductance Multimeter Tools with Case

It can be in the correct order and the diode symbol display two diodes, and gives the diode forward voltage
It can measure capacitance of 30pF-100mF, resolution 1pF
It can be obtained with a single measurement rectifier bridge connection
Notice:Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter
One -button operation, automatic shutdown
Only 20nA shutdown current
Automatic identification components pin arrangement
Measuring bipolar transistor current amplification factor and base - emitter threshold voltage
Via the base - emitter threshold voltage and high current amplification factor to identify transistors
Measuring the gate MOS FET threshold voltage and the gate capacitance
Eeverse breakdown voltage is less than 4.5V Zener diode can be identified
128x64 big Backlight LCD display,only 2mA when stand by
Test range:
Inductors, capacitors , diodes, dual diode , mos, transistor, SCR , the regulator, LED tube , , Resistance,Adjustable potentiometer
Resistance:0.1 Ohm resolution, maximum 50M Ohm
Capacitor:25pf -100,000 uf
Inductors:0.01mh-20H
Protection Case:This case is a protective fitting for LCR-T4 transistor inductor capacitor meter multifunction tester.
Type:With Case
Colour:Yellow
Material:PCB
Size:63x71mm

Package Contents:
1 * Transistor Tester
1 * Acrylic

Only the above package content, other are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
