1.28 Inch IPS Color TFT LCD Display Module 1.28Inch RGB LED Round Screen 240x240 GC9A01 Drive 4 Wire SPI Interface

Resolution:240x240
Pixel size:0.135x0.135mm
Display area:Φ 32.4mm
Driver chip:GC9A01
Working current:20ma (typical)
Interface model:PH2.0-8P/FPCO.5-8P
Equipped with a PH2.0 to female cable
Positioning :M3 screws (fixed to the copper pillar)
Module weight:24g
Notice:
1. The module is compatible with 3.3V and 5V power supplies, and has a level conversion chip on the board. However, it needs to be clear that the user communication level and the power supply voltage need to be consistent. After testing, the for 5V level communication will not work if the 3.3V power supply is used. ESP32 3.3V level communication was tested using 5V and 3.3V power supply, and there were no abnormalities.
2. The screws used to fix the copper pillars are M3 screws. It should be noted that because the copper pillars are through holes and underneath is the metal shell at the bottom of the screen, the part screwed into the copper pillars by the user must not exceed 6mm, otherwise the screen will warp or the edges are cracked.
Colour:Black
Material:PCB+LCD screen
Size:39x36mm

Package Contents:
1 * TFT LCD Display Module
1 * cbale

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
