Dixell XR06CX-5N0C1 230V/50-60Hz 3 Relay Outputs Digital Thermostat Controller Compressor Defrost Fans Adjustable for Ventilated Refrigerating Freezers Units

The XR06CX, format 32x74x60 mm, is microprocessor based controller, suitable for applications on medium or low temperature ventilated refrigerating units. It has three relay outputs to control compressor, fan, and defrost, which can be either electrical or reverse cycle (hot gas).

Specification

Producer: DIXELL

Type: Dixell XR06CX-5N0C1

Mounting Measurements: 71mm x 29mm

Built-in Depth: 56mm

Supply: 230V

Voltage Type: AC

Probe Type: NTC (Probes not included)

Number of Relay Outputs: 1

Relay Output 1: NO-20A(8)

Input: 1NTC

Kind of Protection: IP54

Version: Defrosting Function / Time Control

Measuring Range: -40°C up to +110°C

Display: 2½ Digit

Defrost

Two defrost modes are available through the td parameter:

td=EL defrost through electrical heater (compressor OFF);

td=in hot gas defrost (compressor ON).

Other parameters are used to control the interval between defrost cycles (id), its maximum

length (Md) and two defrost modes: timed or controlled by the evaporator's probe. At the end

of defrost dripping time is started, its length is set in the dt parameter. With dt=0 the dripping

time is disabled.

FANS AND DIGITAL INPUT

When the digital input is configured as door switch iF=do, fans and compressor status

depends on the dC parameter value:

dC=no normal regulation;

dC=Fn fans OFF;

dC=cP compressor OFF;

dC=Fc compressor and fans OFF.

When rd=y, the regulation restart with door open alarm

Package Include

1 X Digital Thermostat Controller (Probes not included)
