CAT5e 100-MHz Shielded Solid Backbone Cable with Foiled Twisted Pair - FTP, White - 2 ft.
CAT5e 100-MHz Shielded Solid Backbone Cable with Foiled Twisted Pair - FTP, White - 2 ft.
Hero image 0 of CAT5e 100-MHz Shielded Solid Backbone Cable with Foiled Twisted Pair - FTP, White - 2 ft., 0 of 1
ServerUSA

CAT5e 100-MHz Shielded Solid Backbone Cable with Foiled Twisted Pair - FTP, White - 2 ft.

(No ratings yet)
CAT5e 100-MHz Shielded Solid Backbone Cable with Foiled Twisted Pair - FTP, White - 2 ft.CAT5e 100 MHz Shielded Solid Backbone Cable with Foiled Twisted Pair FTP 44 White 2 ftCAT5e 100 MHz Shielded Solid Backbone Cable with Foiled Twisted Pair FTP 44 Blue 7 ftCAT5e 100 MHz Shielded Solid Backbone Cable with Foiled Twisted Pair FTP 44 Gray 20 ft
Actual Color:White-Out of stock

Key item features

Features
  • Ideal for use in data, audio, and video applications and for horizontal network connections
  • Cable construction - 24 AWG solid conductor, straight-pinned, 4-pair, T568B, molded boots
  • Shielding - Mylar tape, tinned-copper drain wire; aluminum/Mylar tape
  • Flame-retardant PVC jacket
  • 100-MHz backbone cable for environments requiring no fumes or flames
  • Solid, dependable CAT5e backbone cable for new and existing networks
  • Meets or exceeds CAT5e specifications
Specifications
  • Color: White
  • ACR: 13.3 dB/100 m at 100 MHz
  • ACRF: 23.8 dB/100 m at 100 MHz
  • Attenuation: 22.0 dB/100 m at 100 MHz
  • Cable Outside Diameter - Nominal: 0.23"
  • Capacitance Unbalance - Pair to Ground: 330 pF/100 m maximum
  • Conductor: 24 AWG, solid, bare copper
  • Delay Skew - Maximum: 45 ns/100 m
  • Impedance: 100 ± 15 ohms at 100 MHz
  • Propagation Delay: 538 ns/100 m @ 100 MHz
  • NEXT: 35.3 dB/100 m at 100 MHz
  • PS-ACR: 10.3 dB/100 m at 100 MHz
  • PS-ACRF: 20.8 dB/100 m at 100 MHz
  • PS-NEXT: 32.3 dB/100 m at 100 MHz
  • Return Loss: 20.1 dB/100 m at 100 MHz
  • RoHS: Yes
  • Temperature/Voltage Rating: 167° F at 300 V
  • Jacket: Flame-retardant PVC
  • Standards: UL 444; ISO/IEC 11801; TIA/EIA-568-B.2 CAT5e
  • FEP Insulation: 0.03"
  • Length: 2 ft.
  • Weight: 0.09 lbs
- SKU: ZX9SY2894684
Current price is $11.21
Price when purchased online
Out of stock
