48 Frame Belt Drive Fan & Blower Motor, 1/4 HP, 115V, 1725 RPM, 1.5" Shaft, 8000

Belted Fan & Blower Motor | 1/4 HP | NEMA 48 Frame | 115V | Part #8000

Upgrade your HVAC system with this brand-new belted fan and blower motor, part #8000. Engineered for residential and commercial air-moving applications, this motor features a NEMA 48 frame, split phase design, and reversible rotation for flexible installation. Includes a shaft adapter for 5/8" shafts and combination mounting holes for compatibility with both NEMA 48 and 56 frame dimensions.

⚙️ Product Specifications:

• Electrical Type: Split Phase
• ⚡ Horsepower: 1/4 HP
• Speeds: Single & Two-Speed Capability
• Frame: NEMA 48 (with 48/56 mounting holes)
• Voltage: 115V
• Rotation: Reversible
• RPM: 1725
• ️ Overload Protection: Automatic Reset Thermal Protector
• Amps: 5.3
• Shafts: N-type 1.5" x 5" and U-type 0.5"
• Service Factor: 1.35
• ️ Insulation: Class B
• Mounting: Combination holes for NEMA 48 & 56 frames
• Conduit: Threaded conduit hole for secure wiring
• Condition: Brand New – Unused

✅ Compatible With:

• Residential and commercial HVAC systems
• Belt-driven fans, blowers, and air handlers
• OEM replacement for 1/4 HP split phase motors with NEMA 48 frame

️ Installation Tips:

• Disconnect power before servicing or installing the motor
• Confirm mounting hole alignment for NEMA 48 or 56 frames
• Use shaft adapter for 5/8" blower shafts if required
• Connect wiring per motor diagram and local electrical codes
• Test rotation direction and airflow before final assembly
• Ensure proper belt tension and pulley alignment to prevent wear
