Kennametal LNUX191940-RRP - Railroard Reprofiling Carbide LNUX Insert

single Kennametal brand Railroard Reprofiling Carbide LNUX Insert.

• Material: Carbide
• Insert Style: LNUX
• Insert Size: 191940
• Manufacturer's Grade: KC9125
• Chipbreaker: RP
• Shape: Rectangle
• Width (Decimal Inch): 0.7480
• Thickness (mm): 10.00
• Corner Radius (Inch): 5/32
• Corner Radius (mm): 3.97
• Corner Radius (Decimal Inch): 0.1563
• Relief Angle ( ): 0
• Thickness (Decimal Inch): 0.3937
• Width (mm): 19.00
• Hole Diameter (mm): 6.35
• Hole Diameter (Decimal Inch): 0.2500
• Material Grade: C2/C3/C6/C7
• Coating: TiCN/Al2O3/TiCN/TiN
• Coating Process: CVD
• Included Angle ( ): 90
• Insert Hand: Right Hand
• Length (mm): 19.00
• Length (Decimal Inch): 0.7480
• Maximum Depth of Cut (mm): 1.25
• Maximum Depth of Cut (Decimal Inch): 0.0492
