Miseno Mlk4022 Lorton Flat Bar Passage Door Lever Set - Nickel

Passage: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn't needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.

Features:

• Exceeds criteria for BHMA Grade 3 certification
• Crafted with all metal construction ensuring a durable product
• Intended for left or right handed door configurations
• Easily installs on standard door prep doors
• Includes an adjustable backset and a round corner latch with optional addition of drive-in latch
• Covered under Miseno's 5 year finish and limited lifetime mechanical warranties
• All necessary mounting hardware is included

Specifications:

• Backset: Adjustable 2-3/8" or 2-3/4"
• Cross Bore: 2-1/8"
• Edge Bore: 7/8"
• Door Thickness: 1-3/8" to 1-3/4"
• Handing: Reversible
• Trim Height: 2-9/16"
• Handle Length: 4-1/4"
• Handle Projection: 2-3/8"
• Trim Height: 2-9/16"
• Trim Width: 2-9/16"
• Product Weight:
• Latch Faceplate: Round Corner
