2Pcs 3 Channel PWM Pulse Generator Adjustable Frequency Square Wave Rectangular Wave Signal Generator Module

(No ratings yet)

Key item features

All parameters setted up can be automatically saved in case of power cut.
The value range of dutyfactor: 0~100%,100% is represented by A0%.
Frequency is divided into four areas,automatic switching: 1. XXX(No decimal point): 1HZ Stepping Unit,Range:1Hz~999Hz; 2. X.(The decimal is in place):0.01KHZ Stepping Unit,Range: 1.00Khz~9.99Khz; 3. X.(The decimal is in the tens place):0.1KHZ Stepping Unit,Range: 10.0Khz~99.9Khz; 4. X.X.X(The decimal is in the place):1KHZ Stepping Unit,Range: 1Khz~150Khz;
Three-channel PWM is outputted,wide frequency range and the duty ratio can be adjusted independently
E.g. ,frequency display:100 the pulse of 100Hz ; 1.01 the pulse of 1.01KHz; 54.1 the pulse of 54.1KHz; 1.2.4 the pulse of 124Hz
Has 8 keys,used to set the frequency and duty ratio,support short (increase or decrease a unit) and long (fast increase or decrease),very simple,set the parameters automatically save,power loss.
3-Way duty ratio button can be pressed at the same time,real-time adjustment, liquid crystal display is the last pressed button duty ratio,real-time is very strong,can be used as a simple several road duty ratio scan.
Used as square wave signal generator to generate square wave signal for experiment development and use
Used to generate a square wave signal to control the motor driver;
Generating adjustable pulses for MCU use;
Generate adjustable pulse, control related circuit (PWM dimming speed and other applications).
Color:Photo color
Material:PCB + electronic components
Package Contents: 2 x 3 Channel PWM Pulse Generator Module
