Hero image 0 of DS18 PRO-SM69.2 6" x 9" 500W Max Water Resistant Shallow Mid-Range Loudspeaker, 0 of 6

DS18 PRO-SM69.2 6" x 9" 500W Max Water Resistant Shallow Mid-Range Loudspeaker

Name: DS18 PRO-SM69.2 6" x 9" 500W Max Water Resistant Shallow Mid-Range Loudspeaker
Brand: DS18
SKU: 291630146
Price: 77.95 USD
Availability: InStock
Rating: 5 (1 reviews)

|1 rating

Key item features

Powerful Audio: This 6" x 9" mid-range loudspeaker delivers 250 Watts RMS and 500 Watts peak power, with a sensitivity of 96 dB and a frequency response of 60 Hz-5 KHz.
Durable Construction: Crafted with a water-resistant cone, a cloth edge surround for enhanced accuracy, and a sturdy red steel basket for optimal sound reproduction.
Shallow Design: Features a shallow mounting depth of 2.68 inches (68 mm) and an overall depth of 2.91 inches (74 mm), making it suitable for various installations.
Optimized Impedance: Designed with a 2 Ohm nominal impedance and a 1.5-inch Kapton voice coil with CCAW winding material for efficient power handling.
Compact Dimensions: The loudspeaker has an overall diameter of 9.25" x 6.57" (235 mm x 167 mm) and a front mount baffle cutout of 8.6" x 6" (220 mm x 152 mm).

Generated by AI

Specs

Brand
DS18
Car speaker size class
6x9"
Rms power rating
250 W
Peak audio power handling
500 W
Features
Water-Resistant
Rec. use
Motorcycle

Current price is $77.95

Price when purchased online

Free shipping
Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $12.00

2-Year Plan - $8.00

How do you want your item?

Columbus, 43215

Arrives by Mon, May 4

Only 1 left

Sold and shipped by Pricedrightsales

4.416184971098266 stars out of 5, based on 519 seller reviews(4.4)

Report an issue with this seller

Free 30-day returns

More seller options (3)

Starting from $77.95

About this item

Product details

BRAND NEW

DS18 PRO-SM69.2

6" x 9" 500W Max Water Resistant Shallow Mid-Range Loudspeaker

Crafted with meticulous attention to detail, the PRO-SM69.2 features premium materials that contribute to its exceptional performance. It boasts a water-resistant cone, ensuring that rain or water splashes won't dampen your audio experience. The cloth edge surround enhances sound accuracy and durability, while the red steel basket provides a sturdy foundation for optimal sound reproduction.

Key Features:

SKU: PRO-SM69.2
Nominal Diameter: 6x9" / 152.4 mm x 228.6 mm
Nominal Impedance: 2 OHMS
RMS Power Handing: 250 Watts
Maximum Power Handing: 500 Watts
Sensitivity (1w/1m): 96 dB
Frequency Response: 60 Hz-5 Khz
Recommended Hi Pass Crossover: 120 Hz
Voice Coil Diameter: 1.5" / 38.1 mm
Voice Coil Former Material: Kapton
Winding Material: CCAW
Basket Material: Steel
Magnet Weight: 33 Oz

Thiele & Small Parameters:

Vas: 10.147 L
Xmax: 6.7 mm
Fs: 110 Hz
Qms: 7.358
Qes: 0.959
Qts: 0.848
Re: 2 OHMS

Measurements:

Overall Diameter: 9.25" x 6.57" / 235 mm x 167 mm
Front Mount Baffle Cutout: 8.6" x 6" / 220 mm x 152 mm
Mounting Depth: 2.68" / 68 mm
Overall Depth: 2.91" / 74 mm
Product Weight: 5.5 lbs
Product Dimensions: 10 x 7.25 x 4 in

6 x 9" Shallow Mid-Range Loudspeaker
RMS Power: 250 Watts
Peak Power: 500 Watts
Impedance: 2 Ohm
