512GB SSDNow M.2 SATA 6Gb Compatible with Lenovo IdeaCentre AIO 700 Series, ThinkPad Yoga 370, ThinkPad 11e (4th Gen) Core i3-7100U, Lenovo ThinkPad 13 (2nd Gen) by CMS C82

512GB SSDNow M.2 SATA 6Gbps (Single Side) M.2 Form Factor — Multi-purpose SFF connector replaces small mSATA and mini-PCIe slots Single-sided design (120GB/240GB) — Integrates easily into designs with M.2 connectors; ideal for thin-and-light systems Form factor M.2 2280 Interface SATA Rev. 3.0 (6Gb/s) – with backward compatibility to SATA Rev. 2.0 Capacities 120GB, 240GB Sequential Read/Write SATA Rev. 3.0 120GB - Up to 550/200MB/s 240GB - Up to 550/330MB/s 480GB - Up to 550/520MB/s Max 4k Read/Write IOPS 128GB - up to 100,000/80,000 IOPS Random 4k Read/Write 120GB - up to 80,000/48,000 IOPS 240GB - up to 79,000/79,000 IOPS 480GB - up to 80,000/80,000 IOPS Endurance4 120GB: 150TB and 0.56 DWPD 240GB: 300TB and 0.70 DWPD 480GB: 800TB and 0.93 DWPD Power consumption Max Read: 1.56W Max Write: 3.01W Idle: 0.06W Storage temperature -40°C~85°C Operating temperature 0°C~70°C Dimensions 80mm x 22mm x 3.5mm Weight:256GB - 5.99 (g) Vibration operating 2.17G Peak (7–800Hz) Vibration non-operating 20G Peak (10–2000Hz) Life expectancy 1 million hours MTBF
