INTSUPERMAI 1/2" Radiant PEX Floor Heating Manifold Set Water Distributor 6 Loops

(No ratings yet)

Size:6 Loops

Key item features

【304 STAINLESS STEEL】The main body is made of 304 stainless steel, which is sturdy and reliable. The tube body is demagnetized as a whole, does not absorb impurities, prevents internal clogging, and effectively extends the service life of the water separator than non-demagnetized water separator.
【BALANCED FLOW】The water flow of each branch can be adjusted individually, so that the water flow of each channel will be balanced, and no water grab phenomenon will occur, thereby reducing energy consumption and achieving the purpose of energy saving.
【AUTOMATIC TEMPERATURE CONTROL】The internal copper spring cut-off valve core is used, which can increase the life of the common valve core by more than 3 times. Automatic temperature control can be realized.
【AUTOMATIC DRAINAGE VALVE】Equipped with automatic drainage valve, if there is more gas in the heating water pipe, using the automatic exhaust drainage valve can effectively exclude the body inside the pipe, increase the flow and improve the heating effect.
【VARIETY MODELS】We have a variety of models, including 2/3/4/5/6/7/8/9/10/11/12 branch models, which can meet various needs to the greatest extent.

Specs

Size
6 Loops
Material
Stainless Steel
Brand
intsupermai
Model
S-053265

Current price is $189.00

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives by Sat, May 16

Sold and shipped by ECOSS INC

4.261160714285714 stars out of 5, based on 448 seller reviews(4.3)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Introduction:
In the floor heating system, the mainfold is mainly responsible for the opening and closing of the water flow in the floor heating loop. When the heated water flows into the mainfold through the main pipeline, the water is evenly distributed to the loop, and after heat exchange, the water is returned to the water outlet into the heating system. Widely used for heating system in homes, schools, hotels, swimming pools and other places.

Parameter:
Branch number: Six
Material: Main 304 stainless steel(chromium＞18% nickel＞8%)copper:59 brass
Main connection thread at both ends: G 1" pipe thread
Branch pipe adapter: G 1/2"
Inner diameter of applicable floor heating pipe: 0.47"(12mm)
Spacing of branch pipes: 1.97"(50mm)
Stainless steel tube body thickness: 0.06"(1.6mm)
Temperature control trip: 0.12"(3mm)
Applicable temperature: 1℃-95℃
Applicable pressure: ≤1.5MPa
Applicable medium: Water
Package size: 19.5"*15.9"*3.1"(49.5cm*40.5cm*8cm)
Net weight/Gross weight: 12.0Lb(5.45kg)/15.0LB(6.8kg)

Items Included: S-053265
6 Branches PEX Radiant Floor Heating Manifold Set

【304 STAINLESS STEEL】The main body is made of 304 stainless steel, which is sturdy and reliable. The tube body is demagnetized as a whole, does not absorb impurities, prevents internal clogging, and effectively extends the service life of the water separator than non-demagnetized water separator.
【BALANCED FLOW】The water flow of each branch can be adjusted individually, so that the water flow of each channel will be balanced, and no water grab phenomenon will occur, thereby reducing energy consumption and achieving the purpose of energy saving.
【AUTOMATIC TEMPERATURE CONTROL】The internal copper spring cut-off valve core is used, which can increase the life of the common valve core by more than 3 times. Automatic temperature control can be realized.
【AUTOMATIC DRAINAGE VALVE】Equipped with automatic drainage valve, if there is more gas in the heating water pipe, using the automatic exhaust drainage valve can effectively exclude the body inside the pipe, increase the flow and improve the heating effect.
【VARIETY MODELS】We have a variety of models, including 2/3/4/5/6/7/8/9/10/11/12 branch models, which can meet various needs to the greatest extent.

info:

We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Size

6 Loops

Material

Stainless Steel

Brand

intsupermai

Model

S-053265

Warranty

Warranty information

We provide 30 days return and one year technical support after it is delivered.
