Star Case Elastomeric Shock Isolation Cup Mount-4HARISOMOUNT

Product I.D.:4HARISOMOUNTProduct Dimensions: 2.28" diameter x 1.109" highProduct Material: Steel housing with elastomeric neoprene isolation cushionOverview: Help sensitive equipment defend against high-impact shocks through utilization of Star Case elastomeric shock isolation mounts. They're rugged and versatile and control vibration and interrupt structure-originating noise.Specifications: Under normal loading conditions, shock isolators exhibit natural frequencies of approximately 25 Hz and isolate disturbing frequencies above 35 Hz. Oil resistant standard isolation mounts operate over a temperature range of 20ºF to +180ºF.Installation: View 2-A above shows top view of isolation mount that attaches to equipment in need of shock isolation. View 2-B above shows bottom view of isolation mount that attaches to rigid substrate. Each isolation mount has a through center hole with 1/4-20 thread size. Isolation mounts are manufactured of cold rolled steel (zinc plated) and a neoprene elastomer.Construction: These elastomeric shock isolators are compact, low-profile, and incorporate interlocking components of steel and neoprene elastomers. They are ideal for mounting equipment in compression, shear and tension applications. Regardless of how the mount is oriented or the load is positioned, the elastomer is in compression.Great resistance to severe shock makes these shock isolation mounts ideal for protecting sensitive equipment on rough-terrain vehicles, shipboard equipment, steel or aluminum racks, shipping cases and containers, aircraft, naval and other military applications.
