INTBUYING SPE-LED5060 UV Exposure Unit LED Screen Printing Exposure Unit Exposure Size 54x64cm 110/220V

✍ Description：
1. Max screen frame size: 21 X 25 inch (54x64 cm external diameter)
2. With 8 pcs LED ultraviolet light,
3. Equipped with 8mm tempered glass , keep safety when it was broken
4. Timer will turn off the light automatically according to the setting. It will keep this setting and repeat use unless you change the exposing time.
5. Send 2 pcs black sponge cover on the plate to get a better exposing result.
Count range: 1 second--- 99 hours 59 minutes and 59 seconds
Working temperature: - 25 c --- 65 c
Notice: Different brand emulsion will need variety exposing time, operator need to test with this machine and set to the best exposing time.

✍ Parameters:
Exposure size: 21X25 inch
Product Color: blue
Voltage: 220v/110v universal type
Plug: American standard
Machine using material: steel plate
Machine surface treatment: Electrostatic spraying
Machine size: 26x22x9 inch (67x57x23cm)
Net weight: 79 lb/ 36kg
Gross weight: 90 lb/ 41kg

✍ Countdown Timer Using Method
1. Before using, please press the "C" button to reset, it will display 00:00 00 and flash.
2. Press the "hour" "minute" and "second" button separately to set the countdown time, then the screen shows "ON"
3. Press the "start/restart" button to start work.

✍ Item Included: YX-006854
INTBUYING SPE-LED5060 UV Exposure Unit LED Screen Printing Exposure Unit Exposure Size 54x64cm 110/220V
