Nilight 24V to 12V Voltage Converter 240W 20A Regulator Step Down to 12VDC Waterproof DC Convert Reducer Power Supply Transformer Module for Golf Cart Scooters Trucks

Product description

• Nilight 240W 24V to 12V 20A DC-DC Converter: A high-reliability power transformer with low power consumption, high efficiency, and stable performance, suitable for powering various application devices.
• Core Specifications: 96% high efficiency; DC 24V input voltage; DC 12V output voltage with 20A output current; 0.01A no-load current; ±1.5% voltage accuracy; ±0.2% load regulation rate and linear adjustment rate; IP67 waterproof rating; operating temperature range of -40~85°C.
• Package Contents: 1 x 240W 24V to 12V 20A DC-DC Converter, 2 x Quick Connect Terminals.
• Quick Connect Terminals: Equipped with 2 quick connect terminals for easy wiring. Simply push the lever up with a little force to complete electrical connections quickly.
• Harsh Environment Resistant: Adopts strict glue pouring process with aluminum shell and silicone sealed design, achieving waterproof, moisture-proof and seismic performance, adaptable to a variety of harsh working environments.
• Excellent Heat Dissipation: Die-casted aluminium shell provides excellent corrosion resistance, enhances heat dissipation effect, and ensures sturdiness to extend the service life of the converter.
• Comprehensive Intelligent Protection: Assembled with smart chip and synchronous rectification technology, featuring over-current, over-load, low-load, short-circuit and over-heat protection. When the connected load exceeds the converter’s current-bearing capacity, the power supply will be automatically cut off to safeguard the circuit.
• Troubleshooting Tips: If the converter fails to work, please check the following steps: 1. Confirm whether the power supply has voltage output; 2. Check if terminals have poor contact and wire ends are connected securely; 3. Verify if wires are installed according to the instruction diagram.
