Truck-Mounted Single-Arm Crane, Jib Cranes with Bed-Mounted Base Plate 12V 2000 lb Electric Winch Folding High-Strength Alloy Steel Lift Electric Hoist Truck-Mounted Crane for Industrial Use

1. Basic Attributes

Model: T100

Product Type: Truck-Mounted Single-Arm Crane

Color: Orange and Black

Weight：88LBS

Material: High-Strength Alloy Steel

Mounting Type: Bed-mounted base plate secured with bolts

2. Dimension Parameters

Boom Reach: 47.24 inches to 66.93 inches (approx. 1.2m to 1.7m), extendable

Lifting Height: 59.06 inches to 86.6 inches (approx. 1.5m to 2.2m)

Base Size: 9.2 inches (approx. 23.4 cm)

Cable Length: Short 35.9 inches / Long 47.24 inches

3. Load Capacity

Max Load Capacity: 1100 lbs (approx. 499 kg).

Winch Rated Capacity: 2000 lbs (approx. 907 kg) Electric Winch.

Capacity vs. Boom Length:

At 63.0" Boom Length: Max Capacity 276 lbs (approx. 125 kg).

At 54.3" Boom Length: Max Capacity 551 lbs (approx. 250 kg).

At 45.7" Boom Length: Max Capacity 1104 lbs (approx. 501 kg).

4. Core Configuration

Power Source: 12V DC (connected directly to the truck battery).

Winch: 2000 lbs Electric Winch with steel cable.

Control Method: Wired Remote / Switch.

Rotation Angle: 360° Continuous Rotation.

5. Product Features

Adjustability: Features 3 adjustable boom lengths and 3 adjustable bracket heights for versatile use.

Full-Range Operation: 360° rotational capability provides ultimate flexibility and precision in positioning.

Powerful & Efficient: The 2000 lbs electric winch ensures powerful and smooth lifting performance.

Rugged & Durable: Alloy steel construction guarantees long-term reliability and stability.

Safe & Convenient: Equipped with a wired remote for easy operation from a safe distance.

6. Application Scenarios

Lifting heavy components (e.g., engines, transmissions, equipment) within a truck bed.

Moving and unloading heavy items at construction sites, farms, and warehouses.

Various outdoor work and rescue scenarios that require the movement of heavy objects.
