G1/4" G1" Flow Digital Display Meter Gear Flow Meter Gasoline Oil Hydraulic Oil Soy Oil Water 0.2-10L/min 10-100LPM ,Accurate Measurements

Product name: Gear flowmeter

Applicable medium: gasoline, water, methanol, etc

Product material: plastic, PPS/aluminum/stainless steel, etc

Nominal Diameter: G1/2" G1"

Minimum flow: 0.2L/min

Maximum flow: 100L/min

We also have other relevant products. Please leave us a message befor you make an order.

Function: Can achieve single measurement, total flow, instantaneous measurement

Manual reset

Controls:

1. Hold down the CAL key for 5 seconds to enter the setting of the initial value coefficient. When the number on the screen is blinking, you can operate the RESET key to adjust the number and press the CAL switch coefficient digit.

2. When "is displayed on the initial screen, press RESET once to display TOTAL traffic. To return to the previous screen, press CAL once.

3. Hold down RESET for 5 seconds to clear the total traffic value.

4. Hold down the CAL and RESET buttons for 5 seconds at the same time to enter the unit switch, QTS,PTS,L,GAL, m³ default setting unit: L, press CAL 3 seconds to save the current setting and exit the unit setting interface.

Joint Pipe Bore Size : 1"

Coupling Type : join

Measurement Range : 0.2-100LPM/min

Model Number : COH-110L-02

DIY Supplies : ELECTRICAL

Measure Range(luquid water) : 0.2-10LPM/min,10-100LPM
