Cylinder Head Stud Kit For 97-03 Chevy LS1 LS6 LS2 LQ9 4.8L/5.3L/5.7L/6.0L 33380

Product Description
100% Brand New Items, Never Used Or Installed
THIS IS THE (3) LENGTH HEAD STUDS KIT
IMPORTANT NOTE: Later models had only 2 different length studs in the kit
This is a 190,000 PSI kit that comes complete with 12 point hex nuts and washers
Professional Installation is Highly Recommended (No Instruction Included)

Fitment
For 1997-2003 LS1 LQ9 4.8L 5.3L 5.7L 6.0L engines.

Package Includes
16X long M11 head stud
4X short M11 head stud
10X M8 head stud
20 x big nut with washer
10 x small nut with washer

Note​
Please be very careful to check our photos, make sure the photos showed is the same as you wanted.
Please refer to compatibility chart above for specified vehicle information before purchasing to ensure fitment.

Installation Tips:
Use a thread sealer to lubricate block threads of the head studs (this only works when the cylinder head studs extend into the water jacket).
Screw studs as tight as possible by hand (no tool necessary), and install the cylinder head.
Use a FASTENER ASSEMBLY LUBRICANT (not included) to lubricate the head studs, ensuring nuts and washers are lubricated as well.
Install the lubricated nuts and washer onto the head stud as tight as possible by hand (no tool necessary).
Tighten the cylinder head bolts in 3 equal steps by means of a torque.
