Hero image 0 of Dual Output Ac Dc Converter Switching Power Supply 30W D-30A 5V 12V Power Suply D-30B 5V 24V D-30C 12V 24V ,Stable Input & Output, 0 of 6

Dual Output Ac Dc Converter Switching Power Supply 30W D-30A 5V 12V Power Suply D-30B 5V 24V D-30C 12V 24V ,Stable Input & Output

(No ratings yet)

Dual Output Ac Dc Converter Switching Power Supply 30W D-30A 5V 12V Power Suply D-30B 5V 24V D-30C 12V 24V ,Stable Input & Output Dual Output Ac Dc Converter Switching Power Supply 30W D 30A 5V 12V Power Suply D 30B 5V 24V D 30C 12V 24V Stable Input Output Dual Output Ac Dc Converter Switching Power Supply 30W D 30A 5V 12V Power Suply D 30B 5V 24V D 30C 12V 24V Stable Input Output Dual Output Ac Dc Converter Switching Power Supply 30W D 30A 5V 12V Power Suply D 30B 5V 24V D 30C 12V 24V Stable Input Output

Actual Color:D-30A 5V 12V

Key item features

IN-DOOR USE ONLY!
Switch Power Supply Widely used in Industrial automation, LED display, communications, etc.
You can choose the input voltage by switch.
Smart device surge protection for Shortage Protection, Overload Protection, Over Voltage Protection

Specs

Power transformer type
Step Down
Output voltage
1 mV
Input voltage
1 V
Watts
0 W
Brand
Eugene Color
Volts
1 V

Current price is $43.91

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Columbus, 43215

Arrives between May 14 - May 20

Sold and shipped by VigorMetric

2.9444444444444446 stars out of 5, based on 18 seller reviews(2.9)

Report an issue with this seller

Free 30-day returns - in store or online

About this item

Product details

Specificaiton

Model

D-30A

D-30B

D-30C

output

DC voltage

CH1:5V

CH2:12V

CH1:5V

CH2:24V

CH1:12V

CH2:24V

Voltage tolerance

±2%

+3%~-7%

±2%

+4%~-6%

±2%

+5%~-7%

Rated current

2.2A

Current range

0.5~4A

0.2~1A

0.4~2.2A

0.1~1A

0.3~1A

0.1~1A

Rated power

32W

35W

36W

Ripple&noise

80mvpp

100mvpp

80mvpp

120mvpp

100mvpp

120mvpp

DCvoltage ADJrange

CH1910

input

Voltage range

90132VAC180264VACselected by switch255373VDC

frequency

4763HZ

AC current

08A/115VAC,0.45A/230VAC

efficiency

73%

75%

77%

Inrush current

Cold start current 18A/115VAC,36A/230VAC

Leakage current

< 2mA/240VAC

protection

overload

Rated output power110%~150 start over load protection

protection type :part layer type current limit ,auto-recovery after fault condition is removed

-----

environment

Working temp,humidity

-10°C~+60°C,20%~90%RH

Storagetemp,humidity

-20°C~+85°C,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

Dimension

129*98*38mm (L*W*H)

Weight/packing

0.54kg/24pcs/14kg

note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12 twisted pairwire terminated with a 01uf 47uf parallel capacitor

3 Tolerance includes set up tolerance line regulation and load regulation
