Hubbell Wiring Device-Kellems WllSwtch,Brwn,20A;Bk;Sd,DblPole/DblThrow HBL1386

The HUBBELL Wall Switch is a double pole, double throw (DPDT) industrial-grade toggle switch rated for 20A at 120/277V AC. Designed for back and side wiring, it features a maintained switch function with three handle positions and accommodates #14 to #10 AWG solid or stranded copper wire. The switch is constructed with a durable nylon toggle and housing, For use in industrial environments.Key Features of the HUBBELL Wall Switch: Switch Type: Double Pole Double Throw (DPDT) with center off positionElectrical Ratings: Rated for 20A, 120/277V AC; supports up to 1 horsepowerWiring Method: Back and side wired; screw terminals accommodate #14–#10 AWG copper wireConstruction: Nylon material constructionScrew Terminals: Large brass binding head screws with deep slots for designed to facilitate fasteningStrip Gauge: Integrated strip gauge aids in accurate wiring during installationPerformance Standards: UL Listed and CSA Certified; meets UL 94V-2 flammability requirementsOperating Temperature Range: -40°F to 167°F (-40°C to 75°C)
