Hubbell Wiring Device-Kellems CS8369

The HUBBELL 50A Twist-Lock Receptacle is a locking receptacle suitable for industrial applications, rated for 50 amps and 250V AC. It features a twist-lock mechanism with three poles and four wires, providing connections in indoor environments. The device has a flush mount design and is constructed from impact-modified PBT with a phenolic housing.Key Features of the HUBBELL 50A Twist-Lock Receptacle: Current/Voltage Rating: Rated for 50 amps at 250V AC, suitable for high-capacity electrical systems.Lock Type: Twist-lock configuration is intended to help reduce the likelihood of accidental disconnection.Construction: Impact modified PBT body with phenolic housing has UL 94 V-0 flammability rating.Wire Accommodation: Accepts wire sizes from #10 AWG minimum to #6 AWG maximum; screw terminal connections.NEMA Configuration & Ratings: NEMA enclosure ratings: 1, 4, 4X, and 12Operating Temperature Range: Rated operating temperature range: -40°F to +167°F (-40°C to +75°C continuous).Mounting Type: Can be flush mounted into panels or wall boxes as required by application needs.Standards Compliance: Complies with UL 498 and CSA C22.2 No.42 standards.
