2PC Pop up Floor Outlet Sockets with 2* USB Interfaces&US Standard Interfaces

Are you looking for a beautiful and practical socket? Experience the new trend of future home furnishings and make our pop-up floor socket your smart living solution! Exquisite and fashionable design can blend into most modern decoration styles. The hidden design saves you a lot of space while improving security. Choose it and enjoy a clean space and technological convenience! This product can be widely used in study rooms, offices, living rooms, conference rooms, lecture halls, exhibition halls, and other places. It can be installed on hardwood, carpets, tiles, granite, marble floors, etc.

How to Install

1. Use 2 M3 screws (included) to secure the plastic protective cover to the bottom box to prevent concrete or other objects from falling in.

2. When pouring cement, please first place the box in the designated position. Introduce the wires to be installed into it and reserve a minimum of 7.87 inches. The minimum distance between the box and the ground is 0.79-1.77 inches.

3. After pouring cement, the plastic protective cover can be removed.

4. Connect the wire to the socket.

5. Open the cover plate of the ground socket to expose the screw holes, and use 2 M3 screws to fix the socket to the bottom box.

Specification

Color: Silver

Shape: Square

Material: Stainless Steel, Plastic, Tin-Phosphor Bronze

Process: Baking Paint, Spray Painting

Installation Required: Yes

Mount Type: Floor Mount

Indoor/ Outdoor Use: Indoor

Socket Type: 2* USB Interfaces+ 2* 20A US Standard Interfaces

Pop-up Angle: 45°

Rated Current: 20A

USB Output Current: 4.8A

Rated Power: 4000W

Voltage: 125V

Protection Level: IP44

Bottom Box Size: 100*100*80mm/3.94*3.94*3.15in

Panel Size: 120*120mm/4.72*4.72in

Package Size: 25*12.5*10cm/9.84*4.92*3.94in

Gross Weight: 1.8kg/3.97lbs

Net Weight: 1.65kg/3.64lbs

Package Included

2 * Pop-Up Floor Sockets

2 * English Manuals

Other Accessories for Installation

Notes

Please read the operating manual completely before use. And pay particular attention to the safety instructions included.

This product cannot be installed in bathrooms and kitchens with high humidity, where electrical appliances are concentrated, and where leakage accidents are prone to occur.

This product is suitable for floors with a thickness of 3.15 inches or more. After installation, the sealing ring (included) needs to be tightly attached to the ground.

To avoid the risk of fire, electric shock, and/or death, please turn off the power to the circuit breaker or fuse. Before wiring, it is necessary to test whether the power has been turned off.

This product must be installed and used according to local electrical codes and regulations. This product is recommended to be installed by qualified electricians.

Please pay attention to the orientation of the product during installation. This product can only be installed on the ground.

Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.
