U.S. Solid Electric Solenoid Valve IP65 DC 12V Brass 1/2 inch

(No ratings yet)

U.S. Solid Electric Solenoid Valve IP65 DC 12V Brass 1/2 inch U S Solid 1 2 NPT Electric Solenoid Valve 12V DC Normally Closed Brass U S Solid 1 4 NPT Electric Solenoid Valve 12V DC Normally Closed Brass U S Solid 3 8 NPT Electric Solenoid Valve 12V DC Normally Closed Brass U S Solid 1 NPT Electric Solenoid Valve 12V DC Normally Closed Brass U S Solid 3 4 NPT Electric Solenoid Valve 12V DC Normally Closed Brass

Material:Brass

Size:1/2 in

Key item features

1/2" NPT (USA National Pipe Thread)- Commonly used standard pipe thread in U.S..,SOLID BRASS- This valve's body is made of solid brass (very corrosion resistant material).,UNIDIRECTIONAL- The arrow indicates the flow direction (horizontal mounting please).,DIRECT ACTING and NORMALLY CLOSED- The solenoid s magnetic field with directly moves the plunger and close the orifice for any fluid or gas flow. Only opens while energized.,VITON GASKET- Viton is a space age material that is very chemically inert. As such, it is commonly used with gasoline, kerosine and other organic solvents. Some companies sell solenoid valves with NBR gasket and advertise gasoline use. DO NOT USE NBR gasket for gasoline (it will corrode the gasket and can cause serious gasoline leak and accident or fire). If you intend on using a valve for gasoline, use only VITON gasket.

Specs

Valve type
Stop Valves
Size
1/2 in
Material
Brass
Brand
U.S. Solid
Features
Durable
Has written warranty
No

Current price is $40.59

Price when purchased online

Free shipping
Free 90-day returns

How do you want your item?

I want delivery savings with

Try 30 days of Free Shipping with Walmart+! Choose plan at checkout.

How do you want your item?

Columbus, 43215

Arrives by Tue, May 5

Order within 3 hr 45 min

Sold by Joyfay International LLCPro Seller

Fulfilled by Walmart

4.7384615384615385 stars out of 5, based on 196 seller reviews(4.7)

Report an issue with this seller

Free 90-day returns - in store or online

Get free delivery, shipping and more*

*Restrictions apply

About this item

Product details

U.S. Solid normally closed (N/C) electric solenoid valve is constructed with a durable brass body, 1/2" female threaded (NPT) connections, and strong VITON gasket. Suitable for use with hot or cold water, natural gas, air, very low viscosity fluids (< 20 cst) and gasoline or other petroleum based liquids. Customers chose this general purpose valve for supplemental gas tanks, sprinkler systems, and more.
SPECIFICATION
Size: 1/2"
Flow Aperture: 16 mm
Body Material: Brass
Gasket / Diaphragm / Seal: VITON
Rated voltage: DC 12 V, ±10%
Current: 1A
Power rating: 22 W
Operation Type: Direct Lift Valve
Operation Mode: Normally Closed
Level of protection: IP65
Operational pressure range: 0 to 116 PSI / 0-0.8 MPa (for Air, Water); 0 to 72 PSI / 0-0.5 MPa (for Oil)
Minimum operational temperature: 14 degrees Fahrenheit (-10 degrees Celsius)
Maximum operational temperature: 248 degrees Fahrenheit (120 degrees Celsius)
Flow capacity: 4.8 gallons per minute (GPM) of water at 60oF with a pressure drop of 1 PSI
Flow value: 4.8 Cv
Suitable Media: Air, water, oil, natural gas, diesel fuel, kerosene etc. Can not be used in strong acid, strong base, waste water, industrial gas and other media containing many impurities.
OVERHEATING WARNING: While energized, under normal operating conditions, solenoid valve will get HOT. The coil will reach a maximum temperature of about 80℃. It is fully complied with national standard: JB/T7352-2010. Energized continuously for no more than 24h at a time is recommended.
CA PROP65 WARNING - This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. They are not allowed by federal law to be installed for potable water use in the U.S.A. and its territories.
